Ferrari 296 GTS — [VEHICLE TRIM] - E.35 - FRONT LID SEALS (diagram 0136)
Exploded view of the [vehicle trim] - e.35 - front lid seals on the Ferrari 296 GTS, with 7 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTS [VEHICLE TRIM] - E.35 - FRONT LID SEALS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gts/0136.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 800408 | Ferrari Fastener Button - 800408 | $2.38 | Special order, ships in 7-14 days | |
| 1 | 819615 | Ferrari Guarnizione Vasca Baule - 819615 | $142.04 | Special order, ships in 7-14 days |
| 2 | 918905 | Ferrari RH Front Lid Seal - 918905 | $240.39 | Special order, ships in 7-14 days |
| 3 | 918907 | Ferrari LH Front Lid Seal. - 918907 | $240.39 | Special order, ships in 7-14 days |
| 4 | 793261 | Ferrari RH Stabilus Cover Seal - 793261 | $91.77 | Special order, ships in 7-14 days |
| 5 | 793260 | Ferrari LH Stabilus Cover Seal - 793260 | $91.77 | Special order, ships in 7-14 days |
| 6 | 898273 | Ferrari Fastener Button D.7 - 898273 | $2.38 | Special order, ships in 7-14 days |
