Ferrari 296 GTS — [VEHICLE TRIM] - E.36 - REAR LID TRIM (diagram 0137)
Exploded view of the [vehicle trim] - e.36 - rear lid trim on the Ferrari 296 GTS, with 9 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTS [VEHICLE TRIM] - E.36 - REAR LID TRIM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gts/0137.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14498804 | Ferrari Washer - 14498804 | Superseded | Order 14498824 instead | |
| 1 | 948588 | Ferrari Engine Compartment Lid Windo - 948588 | $3,307.53 | Special order, ships in 7-14 days |
| 2 | 805111 | Ferrari Compl. Engine Compartment Li - 805111 | $295.03 | Special order, ships in 7-14 days |
| 3 | 14501087 | Ferrari Clip - 14501087 | $1.11 | Available, ships in 3-6 days |
| 4 | 872926 | Ferrari Striker Fastener Screw M5 - 872926 | $30.57 | Special order, ships in 7-14 days |
| 5 | 85755000 | Ferrari Striker Plate - 85755000 | $68.83 | Special order, ships in 7-14 days |
| 6 | 12640624 | Ferrari Plain Washer 6mm - 12640624 | $0.31 | Available, ships in 3-6 days |
| 7 | 985357 | Ferrari Rod Fastener Insert - 985357 | $6.96 | Special order, ships in 7-14 days |
| 8 | 959649 | Ferrari Perno Sferico M6 Igus - 959649 | $24.55 | Special order, ships in 7-14 days |
