Ferrari 296 GTS — [VEHICLE TRIM] - E.39 - REAR LID OPENING MECHANISM (diagram 0140)
Exploded view of the [vehicle trim] - e.39 - rear lid opening mechanism on the Ferrari 296 GTS, with 11 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTS [VEHICLE TRIM] - E.39 - REAR LID OPENING MECHANISM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gts/0140.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 290589 | Ferrari Screw 4x8 - 290589 | Superseded | Order 309629 instead | |
| 1 | 878925 | Ferrari Compl. Engine Compartment Li - 878925 | $663.86 | Special order, ships in 7-14 days |
| 1 | 940321 | Ferrari Compl. Engine Compartment Li - 940321 | $614.67 | Special order, ships in 7-14 days |
| 2 | 309629 | Ferrari Screw 4x8 - 309629 | $4.77 | Special order, ships in 7-14 days |
| 3 | 217854 | Ferrari CLAMP - 217854 | $0.52 | Available, ships in 3-6 days |
| 4 | 64215300 | Ferrari Door Rod Clip - 64215300 | $0.82 | Available, ships in 3-6 days |
| 5 | 14569680 | Ferrari Clip - 14569680 | $0.13 | Special order, ships in 7-14 days |
| 5 | 14569880 | Ferrari Clip 14.5x3 - 14569880 | $0.65 | Special order, ships in 7-14 days |
| 6 | 849815 | Ferrari Anti Vibration Damper - 849815 | $51.62 | Available, ships in 3-6 days |
| 7 | 10441290 | Ferrari P Clip Bracket With Sheath 28mm D.10 - 10441290 | $1.02 | Available, ships in 3-6 days |
| 8 | 16281827 | Ferrari Screw 5x14 - 16281827 | $0.46 | Special order, ships in 7-14 days |
