Ferrari 296 GTS — [VEHICLE TRIM] - E.55 - WIPERS AND HEADLAMP WASHERS (diagram 0167)
Exploded view of the [vehicle trim] - e.55 - wipers and headlamp washers on the Ferrari 296 GTS, with 30 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTS [VEHICLE TRIM] - E.55 - WIPERS AND HEADLAMP WASHERS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gts/0167.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 106853 | Ferrari Spring Washer 10mm - 106853 | Superseded | Order 12601474 instead | |
| 10516873 | Ferrari Washer - 10516873 | Superseded | Order 12601474 instead | |
| 12601471 | Ferrari Washer - 12601471 | Superseded | Order 12601474 instead | |
| 12640606 | Ferrari Washer - 12640606 | Superseded | Order 12640678 instead | |
| 12640608 | Ferrari Washer - 12640608 | Superseded | Order 12640678 instead | |
| 12640677 | Ferrari Washer - 12640677 | Superseded | Order 12640678 instead | |
| 1 | 784933 | Ferrari Compl. Windscreen Wiper Asse - 784933 | $1,499.85 | Special order, ships in 7-14 days |
| 1 | 980132 | Ferrari Compl. Windscreen Wiper Asse - 980132 | $1,376.91 | Special order, ships in 7-14 days |
| 2 | 976833 | Ferrari Compl. Driver Side Windscree - 976833 | $1,106.43 | Special order, ships in 7-14 days |
| 2 | 980140 | Ferrari Compl. Driver Side Windscree - 980140 | $909.73 | Special order, ships in 7-14 days |
| 3 | 964764 | Ferrari Driver Side Windscreen Wiper - 964764 | $177.00 | Available, ships in 3-6 days |
| 3 | 980135 | Ferrari Driver Side Windscreen Wiper Blade - 980135 | $150.78 | Available, ships in 3-6 days |
| 4 | 784467 | Ferrari Compl. Passenger Side Windsc - 784467 | $688.45 | Special order, ships in 7-14 days |
| 4 | 980136 | Ferrari Compl. Passenger Side Windsc - 980136 | $639.27 | Special order, ships in 7-14 days |
| 5 | 784468 | Ferrari Passenger Side Windscreen Wiper - 784468 | $190.11 | Available, ships in 3-6 days |
| 5 | 980134 | Ferrari Passenger Side Windscreen Wiper Blade - 980134 | $179.19 | Available, ships in 3-6 days |
| 6 | 15811787 | Ferrari Protective Cap 17 x 10.5 - 15811787 | $1.53 | Available, ships in 3-6 days |
| 7 | 10791021 | Ferrari Nut LHD - 10791021 | $1.25 | Available, ships in 3-6 days |
| 8 | 12601474 | Ferrari Wavy Washer 10mm - 12601474 | $0.06 | Available, ships in 3-6 days |
| 9 | 10903034 | Ferrari Screw 6x35 - 10903034 | $0.82 | Available, ships in 3-6 days |
| 10 | 12640678 | Ferrari Washer 6.15x25x2 - 12640678 | $3.47 | Available, ships in 3-6 days |
| 11 | 921938 | Ferrari Protective Cap - 921938 | $0.73 | Special order, ships in 7-14 days |
| 12 | 921935 | Ferrari Nut - 921935 | $1.11 | Special order, ships in 7-14 days |
| 13 | 12604279 | Ferrari Washer - 12604279 | $0.12 | Available, ships in 3-6 days |
| 13 | 12604274 | Ferrari Wavy Washer 6mm - 12604274 | $0.12 | Available, ships in 3-6 days |
| 14 | 800010 | Ferrari Complete Windscreen Washer C - 800010 | $565.49 | Special order, ships in 7-14 days |
| 14 | 980133 | Ferrari Complete Windscreen Washer C - 980133 | $467.15 | Special order, ships in 7-14 days |
| 15 | 81045300 | Ferrari Screw 6x16 - 81045300 | $1.36 | Special order, ships in 7-14 days |
| 16 | 819125 | Ferrari Clip - 819125 | $0.50 | Special order, ships in 7-14 days |
| 16 | 14569880 | Ferrari Clip 14.5x3 - 14569880 | $0.65 | Special order, ships in 7-14 days |
