Ferrari 296 GTS — [VEHICLE TRIM] - E.61 - BATTERY INSTALLATION (diagram 0174)
Exploded view of the [vehicle trim] - e.61 - battery installation on the Ferrari 296 GTS, with 6 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTS [VEHICLE TRIM] - E.61 - BATTERY INSTALLATION exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gts/0174.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 81911200 | Ferrari Screw - 81911200 | Superseded | Order 85692200 instead | |
| 68176300 | Ferrari Screw 5x12 - 68176300 | Superseded | Order 85692200 instead | |
| 1 | 949914 | Ferrari Complete Battery Fastener Bracket - 949914 | $516.33 | Special order, ships in 7-14 days |
| 1 | 950263 | Ferrari Complete Battery Fastener Bracket - 950263 | $639.27 | Special order, ships in 7-14 days |
| 2 | 14039511 | Ferrari Nut - 14039511 | $0.54 | Available, ships in 3-6 days |
| 3 | 85692200 | Ferrari SCREW M5 x 12 - 85692200 | $0.65 | Available, ships in 3-6 days |
