Ferrari 296 GTS — [ELECTRICAL SYSTEM] - F.14 - HIGH VOLTAGE WIRING HARNESSES (diagram 0189)
Exploded view of the [electrical system] - f.14 - high voltage wiring harnesses on the Ferrari 296 GTS, with 44 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTS [ELECTRICAL SYSTEM] - F.14 - HIGH VOLTAGE WIRING HARNESSES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gts/0189.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 917256 | Ferrari Gogna 2 Vani Con Rinforzo Cn - 917256 | Superseded | Order 961295 instead | |
| 14039614 | Ferrari NUT - 14039614 | $0.40 | Available, ships in 3-6 days | |
| 14440827 | Ferrari Screw (ferrari) - 14440827 | Price on request | Contact us for price and availability | |
| 81911200 | Ferrari Screw - 81911200 | Superseded | Order 85692200 instead | |
| 68176300 | Ferrari Screw 5x12 - 68176300 | Superseded | Order 85692200 instead | |
| 14440834 | Ferrari/Maserati Screw - 14440834 | $1.10 | In stock | |
| 1 | 832663 | Ferrari Y Node - 832663 | $1,967.03 | Special order, ships in 7-14 days |
| 2 | 16281824 | Ferrari Screw - 16281824 | $0.82 | Available, ships in 3-6 days |
| 3 | 985085 | Ferrari Hvc6 Hvb-P2 Inverter Cable - 985085 | $1,873.35 | Special order, ships in 7-14 days |
| 4 | 961295 | Ferrari Gogna 2 Vani Con Rinforzo Cn - 961295 | $10.91 | Special order, ships in 7-14 days |
| 5 | 791886 | Ferrari Hvc6 Cable On Hvb - 791886 | $41.76 | Special order, ships in 7-14 days |
| 6 | 85692200 | Ferrari SCREW M5 x 12 - 85692200 | $0.65 | Available, ships in 3-6 days |
| 7 | 798500 | Ferrari Hvc6-Hvc7 Bracket On Transmi - 798500 | $245.85 | Special order, ships in 7-14 days |
| 8 | 323665 | Ferrari Allen Head Bolt with Washer M6X14 - 323665 | $0.63 | Special order, ships in 7-14 days |
| 9 | 82140000 | Ferrari SCREW - 82140000 | $6.54 | Available, ships in 3-6 days |
| 10 | 961316 | Ferrari Clip - 961316 | $14.84 | Available, ships in 3-6 days |
| 11 | 323668 | Ferrari Screw - 323668 | $0.65 | Special order, ships in 7-14 days |
| 12 | 742156 | Ferrari Cavo Hvc9 Inv.P2-Compressore - 742156 | $688.45 | Special order, ships in 7-14 days |
| 13 | 791897 | Ferrari Bracket Fastening Hvc7 Onto - 791897 | $44.24 | Special order, ships in 7-14 days |
| 14 | 791896 | Ferrari Bracket Fastening Hvc6 Onto - 791896 | $39.31 | Special order, ships in 7-14 days |
| 15 | 742150 | Ferrari HVC8 OBC-P2 Inverter Cable - 742150 | $835.97 | Special order, ships in 7-14 days |
| 16 | 811457 | Ferrari HVB Battery Charger - 811457 | $1,147.41 | Special order, ships in 7-14 days |
| 16 | 830475 | Ferrari HVB Battery Charger - 830475 | $1,873.35 | Special order, ships in 7-14 days |
| 16 | 879949 | Ferrari HVB Battery Charger - 879949 | $1,049.07 | Special order, ships in 7-14 days |
| 16 | 879950 | Ferrari HVB Battery Charger - 879950 | $1,212.98 | Special order, ships in 7-14 days |
| 16 | 879951 | Ferrari HVB Battery Charger - 879951 | $1,147.41 | Special order, ships in 7-14 days |
| 16 | 905975 | Ferrari HVB Battery Charger - 905975 | $1,606.40 | Special order, ships in 7-14 days |
| 16 | 924665 | Ferrari HVB Battery Charger - 924665 | $1,049.07 | Special order, ships in 7-14 days |
| 16 | 966429 | Ferrari HVB Battery Charger - 966429 | $1,049.07 | Special order, ships in 7-14 days |
| 16 | 966430 | Ferrari HVB Battery Charger - 966430 | $1,212.98 | Special order, ships in 7-14 days |
| 16 | 924664 | Ferrari Mrk HVB Battery Charger - UK - 924664 | $1,049.07 | Available, ships in 3-6 days |
| 17 | 890449 | Ferrari Tappo Ferrari Presa Ric. Eur - 890449 | $110.61 | Special order, ships in 7-14 days |
| 18 | 905181 | Ferrari Charge Socket Cord - 905181 | $39.31 | Special order, ships in 7-14 days |
| 19 | 956839 | Ferrari Emergency Charge Socket Actu - 956839 | $3.16 | Special order, ships in 7-14 days |
| 20 | 14059111 | Ferrari Flanged Nut M5 - 14059111 | $0.08 | Available, ships in 3-6 days |
| 20 | 12578021 | Ferrari NUT - 12578021 | Price on request | Contact us for price and availability |
| 20 | 13046014 | Ferrari Nut - 13046014 | $0.63 | Special order, ships in 7-14 days |
| 20 | 14039511 | Ferrari Nut - 14039511 | $0.54 | Available, ships in 3-6 days |
| 21 | 269959 | Ferrari Screw - 269959 | $1.61 | In stock |
| 21 | 68927500 | Ferrari Screw - 68927500 | $0.50 | Special order, ships in 7-14 days |
| 21 | 85692300 | Ferrari Screw M5 x 20 TBFTX - 85692300 | $0.65 | Available, ships in 3-6 days |
| 22 | 885833 | Ferrari Hvc10 Obc-Charge Socket Cabl - 885833 | $1,475.26 | Special order, ships in 7-14 days |
| 22 | 885834 | Ferrari Hvc10 Obc-Charge Socket Cabl - 885834 | $1,770.31 | Special order, ships in 7-14 days |
| 22 | 885832 | Ferrari HVC10 OBC-Charge Socket Cable - 885832 | $1,622.78 | Special order, ships in 7-14 days |
