Ferrari 328 GTB/GTS (1985) — Doors (diagram 110)

Exploded view of the doors on the Ferrari 328 GTB/GTS (1985), with 229 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari 328 GTB/GTS (1985) Doors exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
162303000Ferrari RH Door Assy LHD GTB - 62303000$3,652.97Contact us to order
162303100Ferrari LH Door Assy LHD GTB - 62303100Price on requestContact us to order
162326500Ferrari RH Door Assy LHD GTS - 62326500Price on requestContact us to order
162326600Ferrari LH Door Assy LHD GTS - 62326600Price on requestContact us to order
161809800Ferrari RH Door Assy GTB - 61809800$2,962.80Contact us to order
161809900Ferrari LH Door Assy GTB - 61809900$2,962.80Contact us to order
161814200Ferrari RH Door Assy GTS - 61814200$2,962.80Contact us to order
161814300Ferrari LH Door Assy GTS - 61814300$3,422.91Contact us to order
161857100Ferrari RH Door Assy RHD GTB - 61857100SupersededOrder 62303000 instead
161857200Ferrari LH Door Assy RHD GTB - 61857200Price on requestContact us to order
161873400Ferrari RH Door Assy RHD GTS - 61873400Price on requestContact us to order
161873500Ferrari LH Door Assy RHD GTS - 61873500Price on requestContact us to order
220063202Ferrari Nut - 20063202$14.97Available, ships in 3-6 days
320035606Ferrari RH Exterior Door Lock - 20035606Price on requestContact us for price and availability
320035705Ferrari LH Exterior Door Lock - 20035705Price on requestContact us for price and availability
420035804Ferrari Spacer - 20035804Price on requestContact us for price and availability
520181103Ferrari O-Ring - 20181103$6.67Available, ships in 3-6 days
660046000Ferrari Spring - 60046000$4.81Special order, ships in 7-14 days
761835200Ferrari Door Speakers - 61835200Price on requestContact us for price and availability
861813500Ferrari Rubber Bush - 61813500$1.23Available, ships in 3-6 days
961861700Ferrari RH Door Moulding - 61861700Price on requestContact us for price and availability
961861800Ferrari LH Door Moulding - 61861800Price on requestContact us for price and availability
1061811100Ferrari Inner Door Weatherstrip - 61811100$205.53Available, ships in 3-6 days
1160269206Ferrari RH Rear Moulding GTB - 60269206$34.67Available, ships in 3-6 days
1160601900Ferrari RH Rear Moulding GTS - 60601900Price on requestContact us for price and availability
1160269305Ferrari LH Rear Moulding GTB - 60269305Price on requestContact us for price and availability
1160602000Ferrari LH Rear Moulding GTS - 60602000$28.27Available, ships in 3-6 days
1240127409Ferrari Cap - 40127409$9.74Available, ships in 3-6 days
1320170809Ferrari RH Door Lock - 20170809Price on requestContact us for price and availability
1320170908Ferrari LH Door Lock - 20170908Price on requestContact us for price and availability
14101525Ferrari Bulb 12V-3W - 101525$5.88Available, ships in 3-6 days
1560291200Ferrari Door Warning Light - 60291200$123.35In stock
1560291200/AFerrari Lamp Door Warning - 60291200/A$112.24Available, ships in 3-6 days
1661896600Ferrari Switch Bracket - 61896600Price on requestContact us for price and availability
1762302700Ferrari Window Stop - 62302700$19.01Available, ships in 3-6 days
1860278405Ferrari Rear Rubber - 60278405$142.81Special order, ships in 7-14 days
1962304600Ferrari RH Inner Panel - 62304600Price on requestContact us for price and availability
1962308600Ferrari RH Lining - 62308600$974.76Special order, ships in 7-14 days
1962304700Ferrari LH Inner Panel - 62304700$1,893.38Available, ships in 3-6 days
1961964804Ferrari LH Inner Panel - 61964804$1,893.38Available, ships in 3-6 days
1962308700Ferrari LH Lining - 62308700$841.80Special order, ships in 7-14 days
2062305700Ferrari Plug In Vm8500 - 62305700Price on requestContact us for price and availability
2162303800Ferrari RH Door Armrest - 62303800Price on requestContact us for price and availability
2162303900Ferrari LH Door Armrest - 62303900Price on requestContact us for price and availability
2261803100Ferrari Mirror Switch - 61803100$440.57Available, ships in 3-6 days
2261803100/AFerrari Mirror Switch - 61803100/A$440.57Available, ships in 3-6 days
2362304000Ferrari RH Pocket - 62304000Price on requestContact us for price and availability
2362310900Ferrari RH Lining - 62310900$129.55Special order, ships in 7-14 days
2362304100Ferrari LH Pocket - 62304100Price on requestContact us for price and availability
2362311000Ferrari LH Lining - 62311000Price on requestContact us for price and availability
24126818Ferrari 328 Left Window Switch - 126818$169.72In stock
24126817Ferrari 328 Right Window Switch - 126817$92.40In stock
2561804700Ferrari Courtesy Light - 61804700$198.59Available, ships in 3-6 days
2660101201Ferrari Rubber Boot Cover - 60101201$49.33Available, ships in 3-6 days
2660101200Ferrari Cover - 60101200SupersededOrder 60101201 instead
2715908502Ferrari Screw - 15908502Price on requestContact us for price and availability
2860304805Ferrari RH Plate - 60304805$31.22Available, ships in 3-6 days
2860304904Ferrari LH Plate - 60304904Price on requestContact us for price and availability
2962306300Ferrari RH Door Skin - 62306300$876.72Available, ships in 3-6 days
2962306400Ferrari LH Door Skin - 62306400$1,052.08Available, ships in 3-6 days
3060827500Ferrari RH Door Weather Strip - 60827500$232.05Available, ships in 3-6 days
3060827600Ferrari LH Door Weather Strip - 60827600$232.05Available, ships in 3-6 days
3060827500/KFerrari RH + LH Door Weather Strip Set - 60827500/K$273.61Available, ships in 3-6 days
3160269008Ferrari RH Front Moulding GTB - 60269008$32.99Available, ships in 3-6 days
3160602100Ferrari RH Front Moulding GTS - 60602100$20.03Available, ships in 3-6 days
3160269107Ferrari LH Front Moulding GTB - 60269107$26.83Available, ships in 3-6 days
3160602200Ferrari LH Front Moulding GTS - 60602200$25.40Available, ships in 3-6 days
3260269404Ferrari Plate - 60269404$25.15Available, ships in 3-6 days
3361841300Ferrari Door Handle Cable - 61841300Price on requestContact us for price and availability
3411065775Ferrari Circlip - 11065775Price on requestContact us for price and availability
3562312400Ferrari RH Window Motor - 62312400Price on requestContact us for price and availability
3562312500Ferrari LH Window Motor - 62312500Price on requestContact us for price and availability
3660606500Ferrari RH Bush - 60606500$3.85Available, ships in 3-6 days
3660606600Ferrari LH Bush - 60606600$4.18Available, ships in 3-6 days
37127493Ferrari Spring Washer 5mm - 127493$0.17Available, ships in 3-6 days
37106849Ferrari Spring Washer - 106849SupersededOrder 127493 instead
3862311700Ferrari RH Spring - 62311700$35.48Available, ships in 3-6 days
3862311800Ferrari LH Spring - 62311800$36.92Available, ships in 3-6 days
3914578080Ferrari Door Rod Clip - 14578080$0.19Available, ships in 3-6 days
3940063208Ferrari Door Rod Clip - 40063208$1.48Available, ships in 3-6 days
4062304400Ferrari RH Interior Pocket - 62304400$421.32Available, ships in 3-6 days
4062304500Ferrari LH Interior Pocket - 62304500$349.10Available, ships in 3-6 days
4161329400Ferrari RH Door Lock Servo Passenger - 61329400$1,565.92Special order, ships in 7-14 days
4161329500Ferrari LH Door Lock Servo Driver - 61329500$880.08Special order, ships in 7-14 days
4265859300Ferrari Roll Pin - 65859300$14.34Available, ships in 3-6 days
4260730200Ferrari Pin - 60730200SupersededOrder 65859300 instead
4362304900Ferrari RH Handle Complete LHD - 62304900$1,016.52Available, ships in 3-6 days
4362305000Ferrari LH Handle Complete LHD - 62305000$1,016.52Available, ships in 3-6 days
4461260800Ferrari Door Check Strap - 61260800Price on requestContact us for price and availability
4560566200Ferrari Gasket - 60566200Price on requestContact us for price and availability
4660088705Ferrari Screw - 60088705$3.53Available, ships in 3-6 days
4760251204Ferrari Fixed Hinge - 60251204Price on requestContact us for price and availability
4814304220Ferrari Screw 5x16 - 14304220$0.17Available, ships in 3-6 days
4940120404Ferrari Door Hinge Pin - 40120404$58.71Available, ships in 3-6 days
4920074100Ferrari Door Hinge Pin - 20074100$58.71Available, ships in 3-6 days
5060265808Ferrari RH Rubber GTS - 60265808$82.82Available, ships in 3-6 days
5060265907Ferrari LH Rubber GTS - 60265907$71.13Available, ships in 3-6 days
51168133Ferrari Screw M5 x 20 TBFEI - 168133$1.65Available, ships in 3-6 days
5160815200Ferrari Screw GTS - 60815200$1.65Available, ships in 3-6 days
5261822400Ferrari Door Handle Cable - 61822400$6.46Available, ships in 3-6 days
5360292208Ferrari RH Rear Door Glass Channel GTS - 60292208$214.84Available, ships in 3-6 days
5360292307Ferrari LH Rear Door Glass Channel GTS - 60292307$219.32Available, ships in 3-6 days
5462313200Ferrari RH Exterior Door Handle - 62313200$66.20Available, ships in 3-6 days
5462313300Ferrari LH Exterior Door Handle - 62313300$66.20Available, ships in 3-6 days
5560159605Ferrari 308/328 Lower Door Weatherstrip - 60159605$33.65In stock
5640162307Ferrari Bush - 40162307Price on requestContact us for price and availability
5720170403Ferrari Door Lock Knob - 20170403$11.50Available, ships in 3-6 days
5720170403/AFerrari Door Lock Knob - 20170403/A$42.76Available, ships in 3-6 days
5861920200Ferrari RH Upper Safety Rod - 61920200$24.71Available, ships in 3-6 days
5861923000Ferrari LH Upper Safety Rod - 61923000$26.10Available, ships in 3-6 days
5960591000Ferrari Gasket - 60591000Price on requestContact us for price and availability
6020298303Ferrari Screw - 20298303Price on requestContact us for price and availability
6160292000Ferrari RH Door Glass Frame GTS - 60292000Price on requestContact us for price and availability
6160292109Ferrari LH Door Glass Frame GTS - 60292109$450.24Available, ships in 3-6 days
6160292100Ferrari LH Qtr Light Frame GTS - 60292100SupersededOrder 60292109 instead
6262305100Ferrari RH Moulding - 62305100$127.11Available, ships in 3-6 days
6262305200Ferrari LH Moulding - 62305200$133.46Available, ships in 3-6 days
6360278504Ferrari Door Weatherstrip GTB - 60278504Price on requestContact us for price and availability
6360343100Ferrari Door Weatherstrip GTS - 60343100Price on requestContact us for price and availability
6461841100Ferrari RH Internal Door Handle - 61841100$83.01Available, ships in 3-6 days
6461841200Ferrari LH Internal Door Handle - 61841200$103.81Special order, ships in 7-14 days
6462305300Ferrari RH Inside Door Handle - 62305300SupersededOrder 61841100 instead
6462305400Ferrari LH Inside Door Handle - 62305400Price on requestContact us for price and availability
6561443500Ferrari RH Door Glass Frame GTB - 61443500Price on requestContact us for price and availability
6561443600Ferrari LH Door Glass Frame GTB - 61443600Price on requestContact us for price and availability
6660302205Ferrari Rear Door Glass Felt Channel GTB - 60302205$24.65Available, ships in 3-6 days
6660343308Ferrari Rear Door Glass Felt Channel GTS - 60343308Price on requestContact us for price and availability
66MC3475/2Ferrari Flocked Window Channel Per Metre - MC3475/2$24.51Available, ships in 3-6 days
6720037008Ferrari Door Lock Retaining Captive Clip - 20037008$5.19Available, ships in 3-6 days
67152-30-807-00Ferrari Captive Nut Clip - 152-30-807-00$6.50Available, ships in 3-6 days
6820286704Ferrari Screw GTB - 20286704Price on requestContact us for price and availability
6960266103Ferrari LH Rubber Door Stop - 60266103$21.50In stock
6960266004Ferrari RH Door Stop Rubber GTS - 60266004$79.39Available, ships in 3-6 days
7062327100Ferrari 328 Right Door Glass-62327100$275.00In stock
7060162409Ferrari RH Door Glass GTS - 60162409$987.01Contact us to order
7062320100Ferrari RH Door Glass Complete GTB - 62320100SupersededOrder 62320900 instead
7062320900Ferrari RH Door Glass - 62320900$289.03Contact us to order
7062320200Ferrari LH Door Glass Complete GTB - 62320200$387.19Contact us to order
7062327200Ferrari LH Door Glass Complete GTS - 62327200$738.68Contact us to order
7061879700Ferrari RH Door Glass Complete GTS - 61879700Price on requestContact us to order
7060162508/DFerrari LH Door Glass GTS - 60162508/D$734.33Contact us to order
7140133902Ferrari Plastic Socket For Doorlock Connect Rod - 40133902Price on requestContact us for price and availability
7260302106Ferrari Front Door Window Seal - 60302106$43.96In stock
7260343407Ferrari Front Door Glass Felt Channel Seal GTS - 60343407Price on requestContact us for price and availability
7361328600Ferrari RH Rod - 61328600$3.85Available, ships in 3-6 days
7361328500Ferrari LH Rod - 61328500$3.14Available, ships in 3-6 days
7461021900Ferrari RH Door Mirror LHD - 61021900$3,745.95Available, ships in 3-6 days
7461021800Ferrari LH Door Mirror LHD - 61021800Price on requestContact us for price and availability
7461172800Ferrari RH Door Mirror RHD - 61172800Price on requestContact us for price and availability
7461172700Ferrari LH Door Mirror RHD - 61172700Price on requestContact us for price and availability
7560264405Ferrari RH Front Qtr Light Tinted Glass GTB - 60264405Price on requestContact us to order
7560264504Ferrari LH Front Qtr Light Tinted Glass GTB - 60264504Price on requestContact us to order
7660322500Ferrari Front Qtr Light Rubber GTB - 60322500$235.37Available, ships in 3-6 days
7660519100Ferrari Front Qtr Light Rubber GTS - 60519100Price on requestContact us for price and availability
7660322500/KFerrari Front Qtr Light Rubber GTB Set - 60322500/K$678.46Available, ships in 3-6 days
7762312600Ferrari RH Window Lift Assy - 62312600Price on requestContact us for price and availability
7762312700Ferrari LH Window Lift Assy - 62312700$352.07Available, ships in 3-6 days
7861759900Ferrari Bracket - 61759900Price on requestContact us for price and availability
7950031608Ferrari Lower Mobile Hinge - 50031608$100.95Available, ships in 3-6 days
8050206408Ferrari Countersunk Socket Screw - 50206408$26.26Available, ships in 3-6 days
8160265402Ferrari RH Upper Door Hinge Plate - 60265402Price on requestContact us for price and availability
8160265501Ferrari LH Upper Door Hinge Plate - 60265501Price on requestContact us for price and availability
8262308800Ferrari RH Lower Carpet - 62308800Price on requestContact us for price and availability
8262308900Ferrari LH Lower Carpet - 62308900Price on requestContact us for price and availability
8362313400Ferrari RH Lock Control Lever - 62313400Price on requestContact us for price and availability
8362313500Ferrari LH Lock Control Lever - 62313500Price on requestContact us for price and availability
8462313600Ferrari RH Support - 62313600$34.67Available, ships in 3-6 days
8462316000Ferrari LH Support - 62316000$32.26Available, ships in 3-6 days
8562315900Ferrari Handle Pin - 62315900$11.77Available, ships in 3-6 days
8662314100Ferrari RH Handle Lever - 62314100$111.43Available, ships in 3-6 days
8662314200Ferrari LH Handle Lever - 62314200$118.18Available, ships in 3-6 days
8762313800Ferrari Support - 62313800Price on requestContact us for price and availability
8862314300Ferrari Pin - 62314300$3.66Special order, ships in 7-14 days
8911087276Ferrari E clip - 11087276$0.19Available, ships in 3-6 days
9062315300Ferrari LH Handle Protection - 62315300$62.46Available, ships in 3-6 days
9062315200Ferrari RH Handle Protection - 62315200$61.89Available, ships in 3-6 days
9160709000Ferrari Tie Rod - 60709000$25.68Available, ships in 3-6 days
9260812600Ferrari LH Door Mirror - 60812600Price on requestContact us for price and availability
9261095600Ferrari RH Door Mirror - 61095600$2,827.05Available, ships in 3-6 days
9360991600Ferrari Door Mirror Insert - 60991600Price on requestContact us for price and availability
9413297611Ferrari Screw - 13297611Price on requestContact us for price and availability
61022000Ferrari Bracket - 61022000$87.04Special order, ships in 7-14 days
101528Ferrari Bulb 12v 4w - 101528SupersededOrder 101525 instead
20083309Ferrari Bulb 12V-4W - 20083309SupersededOrder 101525 instead
40134009Ferrari Bush - 40134009Price on requestContact us for price and availability
11065774Ferrari Circlip - 11065774$5.72Available, ships in 3-6 days
60666800Ferrari Door Check Strap Jerky - 60666800$484.57Available, ships in 3-6 days
61220500Ferrari Door Edge Rubber - 61220500Price on requestContact us for price and availability
63026200Ferrari Door Hinge Pin - 63026200$87.30In stock
102248Ferrari Door Light - 102248$87.75Available, ships in 3-6 days
60305901Ferrari Door Weatherstrip GTB - 60305901$232.05Available, ships in 3-6 days
61557800Ferrari Inner Door Gasket - 61557800Price on requestContact us for price and availability
60136207Ferrari Inner/Outer Weatherstrip - 60136207$138.38Available, ships in 3-6 days
401329Ferrari Lamp - 401329SupersededOrder 101525 instead
61964600Ferrari LH Armrest - 61964600Price on requestContact us for price and availability
50143106Ferrari LH Cover - 50143106Price on requestContact us for price and availability
60263605Ferrari LH Door Glass Frame GTB - 60263605Price on requestContact us for price and availability
60636900Ferrari LH Door Lock - 60636900Price on requestContact us for price and availability
60267705Ferrari LH Door Moulding GTB - 60267705Price on requestContact us for price and availability
60415205Ferrari LH Door Moulding GTB - 60415205Price on requestContact us for price and availability
60508300Ferrari LH Door Moulding GTS - 60508300Price on requestContact us for price and availability
60641000Ferrari LH Door Weatherstrip GTS - 60641000$232.05Available, ships in 3-6 days
60162708Ferrari LH Front Qtr Light Blue Tint Glass GTS - 60162708Price on requestContact us to order
61964800Ferrari LH Inner Panel - 61964800Price on requestContact us for price and availability
61998500Ferrari LH Lower Carpet - 61998500Price on requestContact us for price and availability
60056504Ferrari LH Moulding - 60056504Price on requestContact us for price and availability
61409700Ferrari LH Outside RH Inside Gasket - 61409700Price on requestContact us for price and availability
50371608Ferrari Lock Set - 50371608$1,391.50Special order, ships in 7-14 days
60265600Ferrari Lower Hinge Complete - 60265600Price on requestContact us for price and availability
62302200Ferrari Power Window Motor (core charge included in price)-62302200$856.90In stock
62302100Ferrari Power Window Motor Right - 62302100$786.50In stock
61964500Ferrari RH Armrest - 61964500Price on requestContact us for price and availability
50143007Ferrari RH Cover - 50143007Price on requestContact us for price and availability
60263506Ferrari RH Door Glass Frame GTB - 60263506Price on requestContact us for price and availability
60636800Ferrari RH Door Lock - 60636800Price on requestContact us for price and availability
60267606Ferrari RH Door Moulding GTB - 60267606Price on requestContact us for price and availability
60415106Ferrari RH Door Moulding GTB - 60415106Price on requestContact us for price and availability
60508200Ferrari RH Door Moulding GTS - 60508200Price on requestContact us for price and availability
60433703Ferrari RH Door Weatherstrip GTS - 60433703$232.05Available, ships in 3-6 days
60162609Ferrari RH Front Qtr Light Blue Tint Glass GTS - 60162609Price on requestContact us to order
61964700Ferrari RH Inner Panel - 61964700Price on requestContact us for price and availability
61998400Ferrari RH Lower Carpet - 61998400Price on requestContact us for price and availability
60056405Ferrari RH Moulding - 60056405Price on requestContact us for price and availability
61409600Ferrari RH Outside LH Inside Gasket - 61409600Price on requestContact us for price and availability
14441321Ferrari Screw - 14441321Price on requestContact us for price and availability
11195473Ferrari Washer - 11195473SupersededOrder 127493 instead
60343209Ferrari Window Channel GTS - 60343209Price on requestContact us for price and availability
-62312300Ferrari LH Window Lifting Guide With Motor - 62312300$791.70Available, ships in 3-6 days
-62312200Ferrari RH Window Lifting Guide With Motor - 62312200$678.83Available, ships in 3-6 days

All 328 GTB/GTS (1985) diagrams

Loading…
header Logo 3 (1)

120 Kremer Ave. Eatontown, NJ 07724
Corner of Highway 35 and Kremer Ave.
(Mile North of the Mall)

800-631-5589
info@awitalian.com

Mon – Fri 9-6
Sat, Sun closed

NOTE ABOUT IN/OUT OF STOCK

We always attempt to indicate when a part is out of stock. In the event that you order a part and we are currently out of stock, you will be notified within 24 business hours.

Please read our Shipping & Returns Policy for more information

By the same token, we have many parts or can get many parts that may not be found on our site. Please email or call with inquiries.

JOIN OUR MAILING LIST

Receive promotions directly in your email

WE ACCEPT
credit cards 03
TERMS, CONDITIONS, AND PRIVACY

Terms and Conditions & Privacy Policy AW Italian Auto Parts is a division of AW Imported Auto Parts and Service

© 1965 - 2026 • AW ITALIAN is an American Auto Part Dealer for Luxury Italian Vehicles • All Rights Reserved

Go to Top
