Ferrari 330 GT 2+2 Mk.1 — Carburettor (diagram 006)
Exploded view of the carburettor on the Ferrari 330 GT 2+2 Mk.1, with 7 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 40DCZKIT | Ferrari Carburetor Rebuild Kit - 40DCZKIT | $152.90 | In stock |
| 1 | 41530.004 | Ferrari Gasket - 41530.004 | $5.81 | Available, ships in 3-6 days |
| 4 | 37022.001 | Ferrari Filter Lusso (36DCS) - 37022.001 | $32.28 | Available, ships in 3-6 days |
| 6 | 41530.001 | Ferrari Carburettor Fibre Washer 41530.001 - 41530.001 | $3.34 | Available, ships in 3-6 days |
| 7 | 41705.011 | Ferrari Carb Top Gasket 40Dcz6/40Dcl6 - 41705.011 | $14.80 | Available, ships in 3-6 days |
| 51 | 4837 | Ferrari Carb Clamp - 4837 | Price on request | Contact us for price and availability |
| 73 | 64955.002 | Ferrari Stud - 64955.002 | Price on request | Special order, ships in 7-14 days |
