Ferrari 330 GT 2+2 Mk.1 — xternal Side Trim (diagram 215A)
Exploded view of the xternal side trim on the Ferrari 330 GT 2+2 Mk.1, with 18 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 242-44-002-08 | Ferrari RH Gutter Moulding 330 GT Mk1+2 - 242-44-002-08 | Price on request | Contact us for price and availability |
| 1 | 242-44-003-08 | Ferrari LH Gutter Moulding 330 GT Mk1+2 - 242-44-003-08 | Price on request | Contact us for price and availability |
| 2 | 242-44-056-00 | Ferrari RH Door Rubber - 242-44-056-00 | $403.52 | Available, ships in 3-6 days |
| 2 | 242-44-057-00 | Ferrari LH Door Rubber - 242-44-057-00 | $403.52 | Available, ships in 3-6 days |
| 2 | 242-44-056-00/K | Ferrari RH + LH Door Rubber Set - 242-44-056-00/K | $408.98 | Available, ships in 3-6 days |
| 3 | 242-44-220-08 | Ferrari RH Moulding - 242-44-220-08 | Price on request | Contact us for price and availability |
| 3 | 242-44-221-08 | Ferrari LH Moulding - 242-44-221-08 | Price on request | Contact us for price and availability |
| 5 | 60043007 | Ferrari Front Nose Badge Emblem - 60043007 | $367.70 | In stock |
| 5 | 239-44-300-00 | Ferrari Ferrari Motif - 239-44-300-00 | Superseded | Order 60043007 instead |
| 6 | 239-44-320-02 | Ferrari Farina Crown Motif (2 Piece) - 239-44-320-02 | Price on request | Contact us for price and availability |
| 8 | 239-44-330-02 | Ferrari Pininfarina Script Motif - 239-44-330-02 | $138.69 | Available, ships in 3-6 days |
| 9 | 239-44-600-02 | Ferrari Jack Plug/Cover - 239-44-600-02 | $546.82 | Available, ships in 3-6 days |
| 10 | 242-44-620-08 | Ferrari RH Moulding - 242-44-620-08 | Price on request | Contact us for price and availability |
| 10 | 242-44-621-08 | Ferrari LH Moulding - 242-44-621-08 | Price on request | Contact us for price and availability |
| 11 | 242-44-650-07 | Ferrari Moulding - 242-44-650-07 | Price on request | Contact us for price and availability |
| 12 | 134-44-634-01 | Ferrari Sill Moulding Clip - 134-44-634-01 | $19.78 | Available, ships in 3-6 days |
| 12 | 134-44-634-00 | Ferrari Clip - 134-44-634-00 | Superseded | Order 134-44-634-01 instead |
| 13 | 800-44-628-01 | Ferrari Sill Moulding End Clip - 800-44-628-01 | $15.38 | Available, ships in 3-6 days |
