Ferrari 348 CHALLENGE 95 — Fuel Feed System (diagram 006)
Exploded view of the fuel feed system on the Ferrari 348 CHALLENGE 95, with 9 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 153220 | Ferrari Fuel Pipe - 153220 | $549.68 | Available, ships in 3-6 days |
| 2 | 141850 | Ferrari Clamp - 141850 | $2.26 | Available, ships in 3-6 days |
| 3 | 153218 | Ferrari Adaptor - 153218 | $1,674.30 | Special order, ships in 7-14 days |
| 4 | 153219 | Ferrari Fuel Pipe - 153219 | $594.74 | Available, ships in 3-6 days |
| 5 | 13541924 | Ferrari Stud - 13541924 | Price on request | Contact us for price and availability |
| 6 | 140085 | Ferrari Spacer - 140085 | $76.57 | Special order, ships in 7-14 days |
| FER09025 | Ferrari Fuel Tank Sender - FER09025 | $164.89 | In stock | |
| 13541921 | Ferrari Stud - 13541921 | Price on request | Contact us for price and availability | |
| - | 159099 | Ferrari Fuel Pump - 159099 | Price on request | Contact us for price and availability |
