Ferrari 365 GTB4 (Daytona) — Vacuum Pump (1972 Revision) (diagram 040)
Exploded view of the vacuum pump (1972 revision) on the Ferrari 365 GTB4 (Daytona), with 40 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/040.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 350263 | Ferrari Air Pump Clutch - 350263 | Price on request | Contact us for price and availability |
| 1 | 222082 | Ferrari Air Pump Clutch - 222082 | Price on request | Contact us for price and availability |
| 1 | 350239 | Ferrari Air Pump Clutch - 350239 | Price on request | Contact us for price and availability |
| 2 | 350277 | Ferrari Air Pump - 350277 | Price on request | Contact us for price and availability |
| 3 | 350058 | Ferrari Air Pump Shaft - 350058 | $390.16 | Available, ships in 3-6 days |
| 4 | 350045 | Ferrari Spacer - 350045 | $11.40 | Available, ships in 3-6 days |
| 5 | 350044 | Ferrari Spacer - 350044 | Price on request | Contact us for price and availability |
| 6 | 350358 | Ferrari Airpump Drive Belt - 350358 | $120.65 | Available, ships in 3-6 days |
| 7 | 350178 | Ferrari Air Pump Support - 350178 | Price on request | Contact us for price and availability |
| 8 | 350363 | Ferrari Tensioner Bracket - 350363 | Price on request | Contact us for price and availability |
| 9 | 350087 | Ferrari Bolt - 350087 | Price on request | Contact us for price and availability |
| 10 | 350073 | Ferrari Flange - 350073 | $70.51 | Available, ships in 3-6 days |
| 10 | 350236 | Ferrari Clutch Cooling Pipe - 350236 | Price on request | Contact us for price and availability |
| 12 | 350019 | Ferrari Valve - 350019 | Price on request | Contact us for price and availability |
| 13 | 350127 | Ferrari LH Emission Tube - 350127 | Price on request | Contact us for price and availability |
| 13 | 350126 | Ferrari RH Emission Tube - 350126 | Price on request | Contact us for price and availability |
| 14 | 350023 | Ferrari Air Injector - 350023 | Price on request | Contact us for price and availability |
| 15 | 350034 | Ferrari Tube - 350034 | Price on request | Contact us for price and availability |
| 15 | 350353 | Ferrari Tube - 350353 | Price on request | Contact us for price and availability |
| 16 | 9161287 | Ferrari Cylinder Head - 9161287 | $6,568.84 | Available, ships in 3-6 days |
| 16 | 9162196 | Ferrari Cyl Head - 9162196 | Price on request | Contact us for price and availability |
| 16 | 9161287/D | Ferrari RH Cylinder Head - 9161287/D | Price on request | Special order, ships in 7-14 days |
| 16 | 9161287/S | Ferrari LH Cylinder Head - 9161287/S | Price on request | Special order, ships in 7-14 days |
| 17 | 9161437 | Ferrari LH Cam Cover - 9161437 | Price on request | Contact us for price and availability |
| 18 | 9161645 | Ferrari RH Cam Cover - 9161645 | Price on request | Contact us for price and availability |
| 19 | 350055 | Ferrari Gasket - 350055 | Price on request | Contact us for price and availability |
| 20 | 350090 | Ferrari Spacer - 350090 | Price on request | Contact us for price and availability |
| 21 | 30913 | Ferrari Spacer - 30913 | $17.54 | Available, ships in 3-6 days |
| 22 | 350091 | Ferrari Gasket - 350091 | Price on request | Contact us for price and availability |
| 23 | 95041 | Ferrari Washer - 95041 | $0.96 | Available, ships in 3-6 days |
| 25 | 95910200 | Ferrari Nyloc Ringnut - 95910200 | $22.60 | Available, ships in 3-6 days |
| 30 | 95930510 | Ferrari Washer 7R4 - 95930510 | $0.59 | Available, ships in 3-6 days |
| 30 | 12603871 | Ferrari Wavy Washer 7mm - 12603871 | $0.59 | Available, ships in 3-6 days |
| 33 | 10516870 | Ferrari Spring Washer - 10516870 | Price on request | Contact us for price and availability |
| 34 | 95230 | Ferrari Stud - 95230 | Price on request | Contact us for price and availability |
| 41 | 95930511 | Ferrari Washer - 95930511 | $0.59 | Available, ships in 3-6 days |
| 44 | 350131 | Ferrari Pipe - 350131 | Price on request | Contact us for price and availability |
| 50 | 350323 | Ferrari Pipe - 350323 | Price on request | Contact us for price and availability |
| 51 | 350132 | Ferrari Cold Air Screw - 350132 | Price on request | Contact us for price and availability |
| 100564 | Ferrari Valve - 100564 | $549.91 | Special order, ships in 7-14 days |
