Ferrari 365 GTB4 (Daytona) — Dashboard & Instruments (diagram 212B)
Exploded view of the dashboard & instruments on the Ferrari 365 GTB4 (Daytona), with 19 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/212B.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 30008700 | Ferrari Dashboard - 30008700 | Price on request | Contact us to order |
| 1 | 30064703 | Ferrari Dashboard Lining - 30064703 | Price on request | Contact us for price and availability |
| 2 | 30060305 | Ferrari Switch Plate - 30060305 | Price on request | Contact us for price and availability |
| 3 | 10979411 | Ferrari Bolt M6x1 L10 - 10979411 | $0.73 | Available, ships in 3-6 days |
| 4 | 13550211 | Ferrari Flat Washer - 13550211 | Price on request | Contact us for price and availability |
| 5 | 0200918 | Ferrari Screw M4 X 0.7 L 12 - 0200918 | Price on request | Contact us for price and availability |
| 6 | 0200485 | Ferrari Hook - 0200485 | Price on request | Contact us for price and availability |
| 7 | 0200719 | Ferrari Control Lever Shelf - 0200719 | Price on request | Contact us for price and availability |
| 8 | 20072005 | Ferrari Lever Shroud - 20072005 | Price on request | Contact us for price and availability |
| 9 | 20166302 | Ferrari Defrost Control Lever - 20166302 | $544.45 | In stock |
| 9 | 0300486 | Ferrari Heater Lever - 0300486 | Price on request | Contact us for price and availability |
| 10 | 13550011 | Ferrari Washer - 13550011 | Price on request | Contact us for price and availability |
| 12 | 10734011 | Ferrari Nut M4 X 0.7 - 10734011 | Price on request | Contact us for price and availability |
| 13 | 0300579 | Ferrari DOOR HING REINFORCEMENT - 0300579 | Price on request | Contact us for price and availability |
| 14 | 20030003 | Ferrari Bolt M6x1 L30 - 20030003 | Price on request | Contact us for price and availability |
| 15 | 30008908 | Ferrari Glove Box - 30008908 | Price on request | Contact us for price and availability |
| 20033007 | Ferrari Bolt - 20033007 | Price on request | Contact us for price and availability | |
| 50073402 | Ferrari RH Bracket - 50073402 | Price on request | Contact us for price and availability | |
| - | 0201046 | Ferrari Lever Complete - 0201046 | Price on request | Contact us for price and availability |
