Ferrari 365 GTB4 (Daytona) — Window Glass And Seals (diagram 214B)
Exploded view of the window glass and seals on the Ferrari 365 GTB4 (Daytona), with 19 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/214B.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 30083109 | Ferrari Rear Screen Rubber - 30083109 | $1,602.56 | Available, ships in 3-6 days |
| 2 | 30013205 | Ferrari Rear Window Surround - 30013205 | Price on request | Contact us for price and availability |
| 3 | 30248603 | Ferrari Heated Rear Screen - 30248603 | $4,015.42 | Contact us to order |
| 4 | 0300862 | Ferrari Self-Tapping Screw - 0300862 | Price on request | Contact us for price and availability |
| 5 | 30038004 | Ferrari RH Roof Gutter Strip - 30038004 | Price on request | Contact us for price and availability |
| 5 | 30038103 | Ferrari LH Roof Gutter Strip - 30038103 | $306.70 | Special order, ships in 7-14 days |
| 6 | 15611111 | Ferrari Screw - 15611111 | Price on request | Contact us for price and availability |
| 7 | 30012801 | Ferrari RH Brass Door Strip - 30012801 | Price on request | Contact us for price and availability |
| 7 | 30012900 | Ferrari LH Brass Door Strip - 30012900 | Price on request | Contact us for price and availability |
| 8 | 30039408 | Ferrari RH Brass Gutter Strip - 30039408 | Price on request | Contact us for price and availability |
| 8 | 30039507 | Ferrari LH Brass Gutter Strip - 30039507 | Price on request | Contact us for price and availability |
| 10 | MC3477/1 | Ferrari Rear Trunk Weatherstrip Seal - MC3477/1 | $21.26 | In stock |
| 10 | 30020903 | Ferrari Boot Rubber - 30020903 | $19.59 | Available, ships in 3-6 days |
| 11 | 30021000 | Ferrari Boot Rubber - 30021000 | $19.59 | Available, ships in 3-6 days |
| 12 | 20043204 | Ferrari Spring - 20043204 | Price on request | Contact us for price and availability |
| 13 | 20043105 | Ferrari Pininfarina Badge - 20043105 | $64.90 | In stock |
| 14 | 20123105 | Ferrari Door Rubber Seal GTB4 - 20123105 | $24.59 | Available, ships in 3-6 days |
| 14 | MC3476/1 | Ferrari Door Rubber *Per Metre* - MC3476/1 | $24.46 | Available, ships in 3-6 days |
| 15 | 20041505 | Ferrari Door Rubber Outer Per Metre - 20041505 | $78.33 | Available, ships in 3-6 days |
