Ferrari 365 GTB4 (Daytona) — Rear Bumper (diagram 216A)
Exploded view of the rear bumper on the Ferrari 365 GTB4 (Daytona), with 14 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/216A.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 0200644 | Ferrari Screw - 0200644 | Price on request | Contact us for price and availability |
| 6 | 30068803 | Ferrari Carpet - 30068803 | $172.65 | Special order, ships in 7-14 days |
| 7 | 30068902 | Ferrari Carpet - 30068902 | Price on request | Contact us for price and availability |
| 8 | 30008106 | Ferrari Bulkhead - 30008106 | $260.15 | Available, ships in 3-6 days |
| 12 | 30222004 | Ferrari RH Bumper Iron - 30222004 | Price on request | Contact us for price and availability |
| 12 | 30222103 | Ferrari LH Bumper Iron - 30222103 | Price on request | Contact us for price and availability |
| 13 | 30113708 | Ferrari RH Rear Bumper - 30113708 | $6,680.97 | Contact us to order |
| 13 | 30113807 | Ferrari LH Rear Bumper - 30113807 | $11,736.26 | Contact us to order |
| 13 | 30170807 | Ferrari RH Rear Qtr Bumper - 30170807 | Price on request | Contact us for price and availability |
| 13 | 30170906 | Ferrari LH Rear Qtr Bumper - 30170906 | Price on request | Contact us for price and availability |
| 13 | 30113708/K | Ferrari Rear Quarter Bumper Set - 30113708/K | $11,736.26 | Available, ships in 3-6 days |
| 14 | 0300828 | Ferrari Front Bumper Bracket - 0300828 | Price on request | Contact us for price and availability |
| 15 | 30060107 | Ferrari Bumper Rubber Metal Insert - 30060107 | Price on request | Contact us for price and availability |
| 16 | 30028203 | Ferrari Front & Rear Bumper Rubber - 30028203 | $51.52 | Available, ships in 3-6 days |
