Ferrari 365 GTB4 (Daytona) — Door Skin (diagram 221B)
Exploded view of the door skin on the Ferrari 365 GTB4 (Daytona), with 7 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/221B.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 0300334 | Ferrari RH SUPPORT FOR CABLE - 0300334 | Price on request | Contact us for price and availability |
| 1 | 0300335 | Ferrari LH SUPPORT FOR CABLE - 0300335 | Price on request | Contact us for price and availability |
| 2 | 0300344 | Ferrari TUBE FOR CABLE - 0300344 | Price on request | Contact us for price and availability |
| 3 | 30011803 | Ferrari RH Door Skin - 30011803 | $2,146.81 | Contact us to order |
| 3 | 30011902 | Ferrari LH Door Skin - 30011902 | $2,329.32 | Contact us to order |
| 4 | 30033807 | Ferrari RH Window Frame Complete - 30033807 | Price on request | Contact us for price and availability |
| 4 | 30033906 | Ferrari LH Window Frame Complete - 30033906 | Price on request | Contact us for price and availability |
