Ferrari 365 GTB4 (Daytona) — Front Lamp Components (diagram 225B)
Exploded view of the front lamp components on the Ferrari 365 GTB4 (Daytona), with 47 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/225B.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 30044309 | Ferrari Emergency Winder Handle - 30044309 | $37.59 | Special order, ships in 7-14 days |
| 2 | 0300520 | Ferrari FULCRUM BRACKET - 0300520 | Price on request | Contact us for price and availability |
| 3 | 10730500 | Ferrari Thrust Washer - 10730500 | Price on request | Contact us for price and availability |
| 4 | 10615770 | Ferrari Washer - 10615770 | Superseded | Order 10615774 instead |
| 4 | 10615774 | Ferrari Washer - 10615774 | $0.33 | Available, ships in 3-6 days |
| 5 | 12164770 | Ferrari Nut M10 X 1.25 - 12164770 | Price on request | Contact us for price and availability |
| 6 | 30051601 | Ferrari RH Bracket - 30051601 | Price on request | Contact us for price and availability |
| 6 | 0300517 | Ferrari LH Bracket - 0300517 | Price on request | Contact us for price and availability |
| 7 | 0300518 | Ferrari RH REINFORCEMENT FOR THE LAMP POD - 0300518 | Price on request | Contact us for price and availability |
| 7 | 0300519 | Ferrari LH REINFORCEMENT FOR THE LAMP POD - 0300519 | Price on request | Contact us for price and availability |
| 8 | 0300522 | Ferrari RH FRONT BULKHEAD COVER - 0300522 | Price on request | Contact us for price and availability |
| 8 | 0300523 | Ferrari LH FRONT BULKHEAD COVER - 0300523 | Price on request | Contact us for price and availability |
| 9 | 0300216 | Ferrari RH Head Lamp Surround - 0300216 | Superseded | Order 30021604 instead |
| 9 | 30021604 | Ferrari RH Head Lamp Surround - 30021604 | $141.43 | Available, ships in 3-6 days |
| 9 | 0300217 | Ferrari LH Head Lamp Surround - 0300217 | Price on request | Contact us for price and availability |
| 10 | 072320430 | Ferrari INSTALLATION SCREW - 072320430 | Price on request | Contact us for price and availability |
| 11 | 15611001 | Ferrari Self Tapping Screw - 15611001 | Price on request | Contact us for price and availability |
| 12 | 07250512 | Ferrari Seal - 07250512 | Price on request | Contact us for price and availability |
| 13 | 30073704 | Ferrari RH Headlamp Bezel - 30073704 | Price on request | Contact us for price and availability |
| 13 | 30073803 | Ferrari LH Headlamp Bezel - 30073803 | Price on request | Contact us for price and availability |
| 14 | 07320017 | Ferrari FRAME - 07320017 | Price on request | Contact us for price and availability |
| 15 | 50150705 | Ferrari RH Main Beam Unit RHD - 50150705 | Price on request | Contact us for price and availability |
| 15 | 40214500 | Ferrari Carello Main Beam Unit - 40214500 | $196.88 | Available, ships in 3-6 days |
| 15 | 40215100 | Ferrari H/Lamp Unit C/W Side Lamp Only - 40215100 | $237.17 | Available, ships in 3-6 days |
| 15 | 104631 | Ferrari RH Head Lamp Dip Beam Assy RHD - 104631 | $7.46 | Available, ships in 3-6 days |
| 15 | 30255004 | Ferrari RH Dip Headlamp & Side Lamp RHD - 30255004 | $113.31 | Available, ships in 3-6 days |
| 15 | 104632 | Ferrari LH Headlamp Dip Beam Assy RHD - 104632 | $295.45 | Available, ships in 3-6 days |
| 15 | 30255103 | Ferrari LH Headlamp Dip & Side Lamp RHD - 30255103 | $113.31 | Available, ships in 3-6 days |
| 15 | 104605 | Ferrari RH Headlamp Main Beam Assy - 104605 | $193.11 | Available, ships in 3-6 days |
| 15 | 104606 | Ferrari LH Headlamp Main Beam Assy - 104606 | $452.55 | Available, ships in 3-6 days |
| 15 | 106438 | Ferrari Dip Head Lamp Unit Inc Sidelight - 106438 | Price on request | Contact us for price and availability |
| 15 | 102405 | Ferrari RH Dip Beam Lamp Assy (Lhd+S/Light) - 102405 | $252.44 | Available, ships in 3-6 days |
| 15 | 102406 | Ferrari Lh Dip Beam Lamp Assy (Lhd+S/Light) - 102406 | $273.91 | Available, ships in 3-6 days |
| 15 | 102506 | Ferrari RH Dip Beam Assy (RHD+S/Light) - 102506 | $207.59 | Available, ships in 3-6 days |
| 15 | 102507 | Ferrari LH Dip Beam Assy (RHD+S/Light) - 102507 | Price on request | Contact us for price and availability |
| 15 | 102224 | Ferrari RH Main Beam Assy - 102224 | Price on request | Contact us for price and availability |
| 15 | 30254601 | Ferrari RH Main Beam Headlamp(French) - 30254601 | $212.44 | Available, ships in 3-6 days |
| 15 | 30254700 | Ferrari LH Main Beam Headlamp(French) - 30254700 | $212.44 | Available, ships in 3-6 days |
| 15 | 104631/A | Ferrari H/L Mounting Rubber - 104631/A | $7.46 | Available, ships in 3-6 days |
| 15 | 30255004/A | Ferrari RH Head Lamp Bowl - 30255004/A | $113.31 | Available, ships in 3-6 days |
| 15 | 30255103/A | Ferrari LH Head Lamp Bowl - 30255103/A | $113.31 | Available, ships in 3-6 days |
| 15 | 40214500/A | Ferrari Main/High Beam Unit - 40214500/A | $196.88 | Available, ships in 3-6 days |
| 15 | 40215100/A | Ferrari H/Lamp Unit Without Side Lamp - 40215100/A | $237.17 | Available, ships in 3-6 days |
| 20 | 30072706 | Ferrari RH Headlamp Assy - 30072706 | Price on request | Contact us for price and availability |
| 20 | 30072805 | Ferrari LH Headlamp Assy - 30072805 | Price on request | Contact us for price and availability |
| 21 | 30153100 | Ferrari Head Lamp Pivot Bush - 30153100 | Price on request | Contact us for price and availability |
| - | 61083900 | Ferrari Rubber Bump Stop - 61083900 | $0.92 | Available, ships in 3-6 days |
