Ferrari 365 GTC4 — Wheels (diagram 041)
Exploded view of the wheels on the Ferrari 365 GTC4, with 15 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 700510 | Ferrari Road Wheel 7.5"x15" - 700510 | Price on request | Contact us for price and availability |
| 4 | 110524 | Ferrari LH Hub Nut RH Thread - 110524 | $2,901.07 | Available, ships in 3-6 days |
| 4 | 110525 | Ferrari RH Hub Nut LH Thread - 110525 | $2,901.07 | Available, ships in 3-6 days |
| 4 | 700673 | Ferrari RH Hub Nut - 700673 | Superseded | Order 110524 instead |
| 4 | 700703 | Ferrari LH Hub Nut - 700703 | Superseded | Order 110525 instead |
| 5 | 700513 | Ferrari Wheel Centre Hub - 700513 | Price on request | Contact us for price and availability |
| 6 | 700512 | Ferrari Wheel Centre Hub - 700512 | Price on request | Contact us for price and availability |
| 7 | 700514 | Ferrari Wheel Trim - 700514 | Superseded | Order 101233 instead |
| 7 | 101233 | Ferrari Wheel Trim - 101233 | $265.07 | Available, ships in 3-6 days |
| 8 | 700515 | Ferrari Bolt - 700515 | Price on request | Contact us for price and availability |
| 9 | 700516 | Ferrari Locktab - 700516 | Superseded | Order 101235 instead |
| 9 | 101235 | Ferrari 2 Hole Locktab - 101235 | $31.66 | Available, ships in 3-6 days |
| 11 | 700517 | Ferrari Locking Plate - 700517 | Superseded | Order 101236 instead |
| 11 | 101236 | Ferrari Locking Plate 3 hole - 101236 | $35.90 | Available, ships in 3-6 days |
| 109186 | Ferrari Road Wheel 365BB/512BB - 109186 | Price on request | Contact us for price and availability |
