Ferrari 400i — Rear Bumper Components (diagram 211)
Exploded view of the rear bumper components on the Ferrari 400i, with 7 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 255-36-502-00 | Ferrari Rear Bumper - 255-36-502-00 | Superseded | Order 257-36-502-10 instead |
| 1 | 257-36-502-10 | Ferrari Rear Bumper Black - 257-36-502-10 | $6,412.02 | Contact us to order |
| 2 | 255-36-602-03 | Ferrari Rear Bumper Iron - 255-36-602-03 | $25.61 | Available, ships in 3-6 days |
| 3 | 257-36-502-00 | Ferrari Rear Bumper - 257-36-502-00 | $3,953.34 | Contact us to order |
| 4 | 257-36-548-01 | Ferrari RH Rear Bumper Bracket - 257-36-548-01 | $3.33 | Available, ships in 3-6 days |
| 5 | 257-36-549-01 | Ferrari LH Rear Bumper Bracket - 257-36-549-01 | $3.33 | Available, ships in 3-6 days |
| 255-36-602-01 | Ferrari Rear Bumper Iron - 255-36-602-01 | Superseded | Order 255-36-602-03 instead |
