Ferrari 412 — Front Bumper (diagram 209)
Exploded view of the front bumper on the Ferrari 412, with 10 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 257-36-002-00 | Ferrari Front Bumper 412 black - 257-36-002-00 | $6,570.68 | Contact us to order |
| 2 | 257-36-006-00 | Ferrari Qtr Bumper RRH Front 412 Grey Primer - 257-36-006-00 | $2,003.78 | Available, ships in 3-6 days |
| 3 | 257-36-007-00 | Ferrari Qtr Bumper Lh/Frt 412 Greyprimer/rubber - 257-36-007-00 | $2,304.67 | Available, ships in 3-6 days |
| 4 | 255-36-102-03 | Ferrari Front Bumper Iron - 255-36-102-03 | Price on request | Contact us for price and availability |
| 5 | 255-36-232-08 | Ferrari Centre Chrome Strip - 255-36-232-08 | $3,259.34 | Available, ships in 3-6 days |
| 6 | 255-36-236-08 | Ferrari RH Chrome Strip - 255-36-236-08 | $27.75 | Available, ships in 3-6 days |
| 7 | 255-36-237-08 | Ferrari LH Chrome Strip - 255-36-237-08 | $24.44 | Available, ships in 3-6 days |
| 255-36-002-00 | Ferrari Front Bumper - 255-36-002-00 | Superseded | Order 257-36-002-00 instead | |
| 255-36-007-00 | Ferrari LH Qtr Bumper - 255-36-007-00 | Superseded | Order 257-36-007-00 instead | |
| 255-36-006-00 | Ferrari RH Qtr Bumper - 255-36-006-00 | Superseded | Order 257-36-006-00 instead |
