Ferrari 412 — Rear Bumper (diagram 210)
Exploded view of the rear bumper on the Ferrari 412, with 8 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 257-36-502-10 | Ferrari Rear Bumper Black - 257-36-502-10 | $6,412.02 | Contact us to order |
| 2 | 255-36-602-03 | Ferrari Rear Bumper Iron - 255-36-602-03 | $25.61 | Available, ships in 3-6 days |
| 3 | 95408585 | Ferrari RH Rear Under Spoiler - 95408585 | $553.90 | Available, ships in 3-6 days |
| 3 | 257-44-432-07 | Ferrari Rear Under Spoyler RH - 257-44-432-07 | Superseded | Order 95408585 instead |
| 4 | 257-44-433-07 | Ferrari Rear Under Spoyler LH - 257-44-433-07 | $456.97 | Available, ships in 3-6 days |
| 5 | 257-44-930-07 | Ferrari Rear Under Spoyler Centre - 257-44-930-07 | $2,718.86 | Available, ships in 3-6 days |
| 255-36-502-00 | Ferrari Rear Bumper - 255-36-502-00 | Superseded | Order 257-36-502-10 instead | |
| 255-36-602-01 | Ferrari Rear Bumper Iron - 255-36-602-01 | Superseded | Order 255-36-602-03 instead |
