Ferrari 458 Speciale Aperta (Convertible) — Crankshaft - Connecting Rods And Pistons (diagram 002)
Exploded view of the crankshaft - connecting rods and pistons on the Ferrari 458 Speciale Aperta (Convertible), with 30 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/002.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 300599 | Ferrari Crankshaft - 300599 | $3,223.52 | Special order, ships in 7-14 days |
| 2 | 103877 | Ferrari/Maserati Clutch Pilot Bearing - 103877 | $32.95 | In stock |
| 3 | 186201 | Ferrari Key - 186201 | $1.82 | Available, ships in 3-6 days |
| 4 | 268864 | Ferrari Upper Main Half Bearing - 268864 | $41.59 | Available, ships in 3-6 days |
| 4 | 268865 | Ferrari Upper Main Half Bearing - 268865 | $36.69 | Special order, ships in 7-14 days |
| 4 | 268866 | Ferrari Upper Main Half Bearing - 268866 | $39.14 | Special order, ships in 7-14 days |
| 5 | 268869 | Ferrari Lower Main Half Bearing - 268869 | $41.59 | Available, ships in 3-6 days |
| 5 | 268870 | Ferrari Lower Main Half Bearing - 268870 | $36.69 | Special order, ships in 7-14 days |
| 5 | 268871 | Ferrari Lower Half Bearing - 268871 | $39.14 | Special order, ships in 7-14 days |
| 6 | 261727 | Ferrari Crankshaft Bearing Shim - 261727 | $16.69 | Available, ships in 3-6 days |
| 7 | 256341 | Ferrari Engine Damper Flywheel - 256341 | $4,869.88 | Special order, ships in 7-14 days |
| 8 | 229907 | Ferrari Screw M10x1.25x41.5 - 229907 | $17.90 | Special order, ships in 7-14 days |
| 9 | 266912 | Ferrari Torsion Damper - 266912 | $3,307.97 | Special order, ships in 7-14 days |
| 10 | 196216 | Ferrari Screw For Damper Fixing - 196216 | $144.23 | Special order, ships in 7-14 days |
| 11 | 263683 | Ferrari Washer - 263683 | $104.88 | Special order, ships in 7-14 days |
| 12 | 300663 | Ferrari Con Rod and Cap Complete - 300663 | $984.37 | Special order, ships in 7-14 days |
| 13 | 281320 | Ferrari Con Rod Bolt - 281320 | $295.03 | Special order, ships in 7-14 days |
| 14 | 292751 | Ferrari Alignment Pin - 292751 | $44.24 | Special order, ships in 7-14 days |
| 15 | 300758 | Ferrari Bushing - 300758 | $66.35 | Special order, ships in 7-14 days |
| 16 | 306480 | Ferrari RH Cylinder Bank Piston With Rings Complete - 306480 | $1,174.90 | Special order, ships in 7-14 days |
| 16 | 306481 | Ferrari LH Cylinder Bank Piston With Rings Complete - 306481 | $1,174.90 | Special order, ships in 7-14 days |
| 17 | 263328 | Ferrari Piston Ring Set Complete - 263328 | $367.14 | Special order, ships in 7-14 days |
| 18 | 285296 | Ferrari Gudgeon Pin - 285296 | $636.39 | Special order, ships in 7-14 days |
| 19 | 257919 | Ferrari Retainer Ring - 257919 | Price on request | Contact us for price and availability |
| 20 | 304680 | Ferrari Con Rod Half-Bearing - 304680 | $31.93 | Special order, ships in 7-14 days |
| 20 | 304681 | Ferrari Connecting Rod Half-Bearing - 304681 | $34.40 | Special order, ships in 7-14 days |
| 20 | 304682 | Ferrari Connecting Rod Half-Bearing - 304682 | $34.40 | Special order, ships in 7-14 days |
| 20 | 304683 | Ferrari Connecting Rod Half-Bearing - 304683 | $34.40 | Special order, ships in 7-14 days |
| 21 | 309085 | Ferrari Cylinder Sleeve And Piston Kit - 309085 | $17,332.54 | Special order, ships in 7-14 days |
| 264111 | Ferrari Torsion Damper - 264111 | Superseded | Order 266912 instead |
