Ferrari 458 Speciale Aperta (Convertible) — Heat Exchanger (diagram 017)
Exploded view of the heat exchanger on the Ferrari 458 Speciale Aperta (Convertible), with 18 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/017.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 267810 | Ferrari Water/Oil Heat Exchanger - 267810 | $5,350.11 | Special order, ships in 7-14 days |
| 2 | 253104 | Ferrari Gasket Between Heat Exchanger and Crankcase - 253104 | $5.12 | Special order, ships in 7-14 days |
| 3 | 231620 | Ferrari/Maserati Screw - 231620 | $0.58 | In stock |
| 3 | 231621 | Ferrari Allen Screw M6 x 30 TCEI - 231621 | $0.73 | Available, ships in 3-6 days |
| 4 | 192327 | Ferrari Union - 192327 | $7.80 | Special order, ships in 7-14 days |
| 5 | 10284460 | Ferrari Washer - 10284460 | $0.31 | Available, ships in 3-6 days |
| 6 | 267811 | Ferrari Gasket - 267811 | $203.15 | Special order, ships in 7-14 days |
| 7 | 180137 | Ferrari/Maserati Water Temperature Sender / Sensor - 180137 | $25.19 | In stock |
| 8 | 304074 | Ferrari Oil Pressure Sending Unit - 304074 | $286.00 | In stock |
| 9 | 290877 | Ferrari Oil Filter Complete - 290877 | $147.93 | Available, ships in 3-6 days |
| 10 | 280901 | Ferrari/Maserati Oil Filter Cartridge - 280901 | $63.99 | In stock |
| 10 | 458OCSK | Ferrari 458 Oil Change Service Kit - 458OCSK | $72.99 | In stock |
| 10 | CALTOCSK1 | Ferrari California T Oil Change Service Kit - CALTOCSK1 | $97.70 | In stock |
| 11 | 286244 | Ferrari Oil Filter Cap - 286244 | Price on request | Contact us for price and availability |
| 239498 | Ferrari Gasket - 239498 | Superseded | Order 267811 instead | |
| 235444 | Ferrari Oil Filter Cap - 235444 | Price on request | Contact us for price and availability | |
| 216568 | Ferrari Screw 6x30 - 216568 | Superseded | Order 231621 instead | |
| 253318 | Ferrari Water/Oil Heat Exchanger - 253318 | Superseded | Order 267810 instead |
