Ferrari 458 Speciale Aperta (Convertible) — Gearbox Oil Cooling Radiators (diagram 022)
Exploded view of the gearbox oil cooling radiators on the Ferrari 458 Speciale Aperta (Convertible), with 39 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/022.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 295369 | Ferrari RH Radiator - 295369 | $2,168.01 | Special order, ships in 7-14 days |
| 1 | 295371 | Ferrari LH Radiator - 295371 | $2,792.77 | Special order, ships in 7-14 days |
| 2 | 14054577 | Ferrari Domed Nut - 14054577 | $0.59 | Available, ships in 3-6 days |
| 3 | 12648978 | Ferrari Washer - 12648978 | $1.04 | Available, ships in 3-6 days |
| 4 | 255048 | Ferrari Grommet Shim - 255048 | $5.65 | Special order, ships in 7-14 days |
| 5 | 255047 | Ferrari Grommet - 255047 | $7.40 | Available, ships in 3-6 days |
| 6 | 277070 | Ferrari Electric Fan Complete - 277070 | $467.15 | Special order, ships in 7-14 days |
| 7 | 155751 | Ferrari Clip - 155751 | $8.49 | Available, ships in 3-6 days |
| 8 | 257824 | Ferrari Bracket - 257824 | $8.39 | Available, ships in 3-6 days |
| 9 | 83002700 | Ferrari RH Air On Oil Radiator - 83002700 | $183.56 | Available, ships in 3-6 days |
| 9 | 83002200 | Ferrari LH Air On Oil Radiator - 83002200 | $183.56 | Special order, ships in 7-14 days |
| 10 | 11566224 | Ferrari Screw 5x14 - 11566224 | $0.77 | Available, ships in 3-6 days |
| 11 | 12638178 | Ferrari Washer 5.45-14x1 - 12638178 | $0.13 | Available, ships in 3-6 days |
| 12 | 168698 | Ferrari Nut M5 x 11 - 168698 | $3.68 | Available, ships in 3-6 days |
| 14 | 14189071 | Ferrari M6 x 1Screw clip - 14189071 | $1.36 | Available, ships in 3-6 days |
| 14 | 66927700 | Ferrari Bracket with Collar - 66927700 | $1.99 | Available, ships in 3-6 days |
| 15 | 264386 | Ferrari Protective Foam For Oil Radiators - 264386 | $7.80 | Special order, ships in 7-14 days |
| 16 | 83021900 | Ferrari LH Air Duct - 83021900 | $514.01 | Available, ships in 3-6 days |
| 16 | 83021800 | Ferrari RH Air Duct - 83021800 | $514.01 | Special order, ships in 7-14 days |
| 17 | 83002900 | Ferrari RH Air Duct On Bodyshell - 83002900 | $440.56 | Special order, ships in 7-14 days |
| 17 | 83002500 | Ferrari LH Air Duct On Bodyshell - 83002500 | $440.56 | Special order, ships in 7-14 days |
| 18 | 16285127 | Ferrari Screw M5 x 16 - 16285127 | $1.05 | Special order, ships in 7-14 days |
| 19 | 12643701 | Ferrari Flat Washer - 12643701 | $0.12 | Available, ships in 3-6 days |
| 20 | 11625824 | Ferrari Screw 6x18 - 11625824 | $0.71 | Available, ships in 3-6 days |
| 21 | 16281827 | Ferrari Screw 5x14 - 16281827 | $0.46 | Special order, ships in 7-14 days |
| 22 | 12643724 | Ferrari/Maserati Washer - 12643724 | $0.20 | In stock |
| 257823 | Ferrari Electric Fan Complete - 257823 | Superseded | Order 277070 instead | |
| 261257 | Ferrari LH Radiator - 261257 | Superseded | Order 295371 instead | |
| 14054042 | Ferrari Nut - 14054042 | Superseded | Order 168698 instead | |
| 14054048 | Ferrari Nut - 14054048 | Superseded | Order 168698 instead | |
| 260784 | Ferrari RH Air Duct - 260784 | Superseded | Order 83021800 instead | |
| 261256 | Ferrari RH Radiator - 261256 | Superseded | Order 295369 instead | |
| 85833700 | Ferrari SCREW - 85833700 | $0.65 | Available, ships in 3-6 days | |
| 12638108 | Ferrari Washer - 12638108 | Superseded | Order 12638178 instead | |
| 12638177 | Ferrari Washer - 12638177 | Superseded | Order 12638178 instead | |
| 12643711 | Ferrari Washer - 12643711 | Superseded | Order 12643724 instead | |
| 12643721 | Ferrari Washer - 12643721 | Superseded | Order 12643724 instead | |
| 14499301 | Ferrari Washer - 14499301 | Superseded | Order 12643724 instead | |
| 61276300 | Ferrari Washer - 61276300 | Superseded | Order 12638178 instead |
