Ferrari 458 Speciale Aperta (Convertible) — Headliner Trim And Accessories (diagram 109)

Exploded view of the headliner trim and accessories on the Ferrari 458 Speciale Aperta (Convertible), with 62 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari 458 Speciale Aperta (Convertible) Headliner Trim And Accessories exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
413311677Ferrari Screw - 13311677$1.17Special order, ships in 7-14 days
1384456200Ferrari RH Switch Surround - 84456200$19.91Special order, ships in 7-14 days
1484456300Ferrari LH Switch Surround - 84456300$19.91Special order, ships in 7-14 days
15232106Ferrari Dome Lamp Complete - 232106SupersededOrder 309925 instead
15309925Ferrari Dome Lamp Complete - 309925$1,395.20Available, ships in 3-6 days
15238482Ferrari Dome Lamp Complete - 238482SupersededOrder 309924 instead
15239904Ferrari Dome Lamp Complete - 239904SupersededOrder 309923 instead
15239905Ferrari Dome Lamp Complete - 239905$1,419.67Special order, ships in 7-14 days
15256579Ferrari Dome Lamp Complete - 256579SupersededOrder 309930 instead
15256580Ferrari Dome Lamp Complete - 256580SupersededOrder 309929 instead
15309929Ferrari Dome Lamp Complete - 309929$1,468.65Available, ships in 3-6 days
15256581Ferrari Dome Lamp Complete - 256581SupersededOrder 309926 instead
15256583Ferrari Dome Lamp Complete - 256583SupersededOrder 309928 instead
15309921Ferrari Dome Lamp Complete - 309921$1,346.25Special order, ships in 7-14 days
15309923Ferrari Dome Lamp Complete - 309923$1,346.25Special order, ships in 7-14 days
15309924Ferrari Dome Lamp Complete - 309924$1,395.20Special order, ships in 7-14 days
15309926Ferrari Dome Lamp Complete - 309926$1,444.15Special order, ships in 7-14 days
15309928Ferrari Dome Lamp Complete - 309928$1,444.15Special order, ships in 7-14 days
15309930Ferrari Dome Lamp Complete - 309930$1,468.65Special order, ships in 7-14 days
16241287Ferrari Plate - 241287$110.13Special order, ships in 7-14 days
1786630100Ferrari LH Trim Mounting Bracket - 86630100$119.91Special order, ships in 7-14 days
1814040514Ferrari Flanged Nut - 14040514SupersededOrder 13046011 instead
1983604700Ferrari LH Mounting - 83604700$176.22Special order, ships in 7-14 days
1983604800Ferrari RH Mounting - 83604800$176.22Special order, ships in 7-14 days
2085833700Ferrari SCREW - 85833700$0.65Available, ships in 3-6 days
20169814Ferrari Screw M5 x 14 TBFEI - 169814$2.61Available, ships in 3-6 days
2112638178Ferrari Washer 5.45-14x1 - 12638178$0.13Available, ships in 3-6 days
2268176500Ferrari Screw 5x20 - 68176500$1.02Available, ships in 3-6 days
2384707900Ferrari Flank Adjustment Shim - 84707900$5.65Special order, ships in 7-14 days
2683431600Ferrari Rear Screen Waterproof Membrane - 83431600$201.88Special order, ships in 7-14 days
2687048300Ferrari Rear Screen Waterproof Membr - 87048300$391.61Special order, ships in 7-14 days
2883878300Ferrari Lateral Cover Mounting Bracket - 83878300$36.92Special order, ships in 7-14 days
3284278600Ferrari Upper Pillar Vibration Damper - 84278600$4.41Special order, ships in 7-14 days
3384278700Ferrari Lower Pillar Vibration Damper - 84278700$3.41Special order, ships in 7-14 days
3483572200Ferrari LH Lower Side Panel Bracket - 83572200$36.92Special order, ships in 7-14 days
3483572100Ferrari RH Lower Side Panel Bracket - 83572100$36.92Special order, ships in 7-14 days
3514304220Ferrari Screw 5x16 - 14304220$0.17Available, ships in 3-6 days
3612647727Ferrari Washer 6X21 - 12647727$0.12Special order, ships in 7-14 days
3714302924Ferrari Screw - 14302924$0.44Available, ships in 3-6 days
3814446924Ferrari Washer - 14446924$0.54Available, ships in 3-6 days
4014498801Ferrari Washer - 14498801$0.19Available, ships in 3-6 days
4181078300Ferrari Shim - 81078300$5.63Special order, ships in 7-14 days
4181988000Ferrari Shim - 81988000$5.63Special order, ships in 7-14 days
42266000Ferrari Clip - 266000$1.80Special order, ships in 7-14 days
4415900201Ferrari Screw - 15900201$0.90Special order, ships in 7-14 days
4585796700Ferrari Screw - 85796700$0.79Special order, ships in 7-14 days
4612639901Ferrari Washer - 12639901$0.17Available, ships in 3-6 days
47292422Ferrari Passenger Compartment Telemetry Camera - 292422$7,958.75Special order, ships in 7-14 days
4865752800Ferrari Screw M4 x 10 TBEI - 65752800$4.12Available, ships in 3-6 days
4914188971Ferrari Screw Clip - 14188971$9.07Special order, ships in 7-14 days
5086766000Ferrari Camera Fastener Bracket LHD - 86766000$48.93Special order, ships in 7-14 days
5086909400Ferrari Camera Fastener Bracket RHD - 86909400$48.93Special order, ships in 7-14 days
312136Ferrari Dome Lamp Complete - 312136SupersededOrder 309924 instead
312138Ferrari Dome Lamp Complete - 312138SupersededOrder 309921 instead
312141Ferrari Dome Lamp Complete - 312141SupersededOrder 309926 instead
13046011Ferrari Flanged Nut - 13046011$0.73Available, ships in 3-6 days
11566224Ferrari Screw 5x14 - 11566224$0.77Available, ships in 3-6 days
14368371Ferrari Screw Clip - 14368371SupersededOrder 14188971 instead
12638108Ferrari Washer - 12638108SupersededOrder 12638178 instead
12638177Ferrari Washer - 12638177SupersededOrder 12638178 instead
61276300Ferrari Washer - 61276300SupersededOrder 12638178 instead
12647729Ferrari Washer 6.45-21X - 12647729$0.13Special order, ships in 7-14 days

All 458 Speciale Aperta (Convertible) diagrams
