Ferrari 488 Pista Spider — Engine Flywheel (diagram 009)
Exploded view of the engine flywheel on the Ferrari 488 Pista Spider, with 3 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 340464 | Ferrari Engine Flywheel - 340464 | $5,433.37 | Special order, ships in 7-14 days |
| 2 | 336406 | Ferrari Screw - 336406 | Superseded | Order 328629 instead |
| 328629 | Ferrari Screw M10 x 1.25 - 328629 | $159.75 | Available, ships in 3-6 days |
