Ferrari 488 Pista Spider — Vacuum Pump (diagram 024)
Exploded view of the vacuum pump on the Ferrari 488 Pista Spider, with 9 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 341928 | Ferrari Depressore Bosch - 341928 | $1,181.86 | Special order, ships in 7-14 days |
| 2 | 333545 | Ferrari Coperchio Per Sede Depresso - 333545 | $150.17 | Special order, ships in 7-14 days |
| 3 | 335257 | Ferrari Gasket - 335257 | $29.52 | Special order, ships in 7-14 days |
| 4 | 231628 | Ferrari Screw 8x25 - 231628 | $1.15 | Special order, ships in 7-14 days |
| 5 | 338896 | Ferrari Bracket - 338896 | $23.86 | Special order, ships in 7-14 days |
| 6 | 839366 | Ferrari Bumper - 839366 | $15.29 | Special order, ships in 7-14 days |
| 7 | 338653 | Ferrari Bracket - 338653 | $27.06 | Special order, ships in 7-14 days |
| 951041 | Ferrari Bumper - 951041 | $15.95 | Special order, ships in 7-14 days | |
| 834367 | Ferrari Screw 8x25 - 834367 | Superseded | Order 231628 instead |
