Ferrari 488 Pista Spider — Alternator (diagram 037)

Exploded view of the alternator on the Ferrari 488 Pista Spider, with 24 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari 488 Pista Spider Alternator exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
1309645Ferrari 488 Alternator - 309645$887.80In stock
214359534Ferrari Screw - 14359534$3.03Special order, ships in 7-14 days
311193874Ferrari Washer D.8.4-16x1.4 - 11193874$0.12Available, ships in 3-6 days
4826428Ferrari Alternator Brace Bracket - 826428$59.07Special order, ships in 7-14 days
5849746Ferrari Alternator Shield - 849746$44.29Special order, ships in 7-14 days
616102314Ferrari Nut M8 x 5 - 16102314$0.13Available, ships in 3-6 days
712601374Ferrari Wavy Washer 8mm - 12601374$3.12Available, ships in 3-6 days
8231617Ferrari Screw M6 x 18 TCEI - 231617SupersededOrder 14433124 instead
319834Ferrari Alternator Brace Bracket - 319834Price on requestContact us for price and availability
325145Ferrari Alternator Brace Bracket - 325145$61.16Special order, ships in 7-14 days
284592Ferrari Alternator Shield - 284592$119.91Special order, ships in 7-14 days
311598Ferrari Alternator Shield - 311598$115.02Special order, ships in 7-14 days
325525Ferrari Alternator Shield - 325525Price on requestContact us for price and availability
16100825Ferrari Nut - 16100825SupersededOrder 16102314 instead
16102315Ferrari Nut - 16102315SupersededOrder 16102314 instead
16100821Ferrari Plain Nut 8mm x 6.25mm Pitch 1.25 - 16100821SupersededOrder 16102314 instead
16102311Ferrari RH Thread Nut - 16102311SupersededOrder 16102314 instead
14433121Ferrari Screw - 14433121SupersededOrder 231617 instead
10615670Ferrari Washer - 10615670SupersededOrder 12601374 instead
10615671Ferrari Washer - 10615671SupersededOrder 12601374 instead
10615674Ferrari Washer - 10615674SupersededOrder 12601374 instead
10615679Ferrari Washer - 10615679SupersededOrder 12601374 instead
12601370Ferrari Washer - 12601370SupersededOrder 12601374 instead
12601379Ferrari Washer - 12601379SupersededOrder 12601374 instead

All 488 Pista Spider diagrams
