Ferrari 488 Pista Spider — Engine Injection Control (diagram 049)
Exploded view of the engine injection control on the Ferrari 488 Pista Spider, with 6 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 337737 | Ferrari Ignition ECU - 337737 | $2,442.40 | Special order, ships in 7-14 days |
| 2 | 313125 | Ferrari Ignition ECU - 313125 | $2,084.11 | Special order, ships in 7-14 days |
| 3 | 310876 | Ferrari Ecu Bracket - 310876 | $152.62 | Special order, ships in 7-14 days |
| 4 | 310877 | Ferrari Ecu Mounting Bracket - 310877 | $59.07 | Special order, ships in 7-14 days |
| 5 | 231617 | Ferrari Screw M6 x 18 TCEI - 231617 | Superseded | Order 14433124 instead |
| 14433121 | Ferrari Screw - 14433121 | Superseded | Order 231617 instead |
