Ferrari 488 Pista Spider — Front Shields (diagram 112)
Exploded view of the front shields on the Ferrari 488 Pista Spider, with 11 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 89266900 | Ferrari Compl. Front RH Underbody Shield - 89266900 | $465.04 | Special order, ships in 7-14 days |
| 2 | 89266700 | Ferrari Compl. Front LH Underbody Shield - 89266700 | $465.04 | Special order, ships in 7-14 days |
| 3 | 768517 | Ferrari RH Central Front Dam - 768517 | $226.49 | Special order, ships in 7-14 days |
| 4 | 768516 | Ferrari LH Central Front Dam - 768516 | $226.49 | Special order, ships in 7-14 days |
| 5 | 86481400 | Ferrari RH Front Inner Dam - 86481400 | $71.38 | Special order, ships in 7-14 days |
| 6 | 86481300 | Ferrari LH Front Inner Dam - 86481300 | $71.38 | Special order, ships in 7-14 days |
| 7 | 81290900 | Ferrari Screw With Double Washer - 81290900 | $1.42 | In stock |
| 8 | 256490 | Ferrari Screw TBEI M5 x 16 - 256490 | $3.91 | Available, ships in 3-6 days |
| 8 | 86607000 | Ferrari Screw - 86607000 | Superseded | Order 256490 instead |
| 9 | 12643701 | Ferrari Flat Washer - 12643701 | $0.12 | Available, ships in 3-6 days |
| 10 | 85833900 | Ferrari Screw M5 x 16 TBFTX - 85833900 | $0.65 | Available, ships in 3-6 days |
