Ferrari 488 Pista Spider — Rear Lid Lock (diagram 137)
Exploded view of the rear lid lock on the Ferrari 488 Pista Spider, with 5 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 84076100 | Ferrari Engine Compartment Lid Lock - 84076100 | $216.66 | Special order, ships in 7-14 days |
| 2 | 14569680 | Ferrari Clip - 14569680 | $0.13 | Special order, ships in 7-14 days |
| 3 | 12647604 | Ferrari Washer - 12647604 | $0.12 | Available, ships in 3-6 days |
| 4 | 14059214 | Ferrari Flanged Nut M6 - 14059214 | $0.38 | Available, ships in 3-6 days |
| 5 | 217854 | Ferrari CLAMP - 217854 | $0.52 | Available, ships in 3-6 days |
