Ferrari 488 Pista Spider — Dct Gearbox System (diagram 186)
Exploded view of the dct gearbox system on the Ferrari 488 Pista Spider, with 3 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 330778 | Ferrari DCT Gearbox ECU - 330778 | $2,341.71 | Special order, ships in 7-14 days |
| 2 | 86626400 | Ferrari Dct ECU Bracket - 86626400 | $71.38 | Special order, ships in 7-14 days |
| 3 | 11625824 | Ferrari Screw 6x18 - 11625824 | $0.71 | Available, ships in 3-6 days |
