Ferrari 488 Pista — [ENGINE] - B.26 - ENGINE HEAT EXCHANGER (diagram 0031)
Exploded view of the [engine] - b.26 - engine heat exchanger on the Ferrari 488 Pista, with 4 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 488 Pista [ENGINE] - B.26 - ENGINE HEAT EXCHANGER exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/488-pista/0031.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 299064 | Ferrari Heat Exchanger - 299064 | Superseded | Order 299065 instead | |
| 1 | 299065 | Ferrari Heat Exchanger - 299065 | $1,600.44 | Special order, ships in 7-14 days |
| 2 | 272498 | Ferrari Heat Exchanger Gasket - 272498 | $21.14 | Available, ships in 3-6 days |
| 3 | 231618 | Ferrari Allen Head Screw M6x20 TCEI - 231618 | $0.57 | Available, ships in 3-6 days |
