Ferrari 488 Pista — [MECHANICAL SYSTEM] - D.15 - EXPANSION TANK (diagram 0064)

Exploded view of the [mechanical system] - d.15 - expansion tank on the Ferrari 488 Pista, with 17 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari 488 Pista [MECHANICAL SYSTEM] - D.15 - EXPANSION TANK exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
321089Ferrari Coolant Reservoir - 321089SupersededOrder 332129 instead
14433121Ferrari Screw - 14433121SupersededOrder 231617 instead
1332129Ferrari Coolant Reservoir - 332129$517.04Special order, ships in 7-14 days
2145030Ferrari Radiator Cap - 145030$89.98In stock
3813422Ferrari Compl. Header Tank Rigid Dra - 813422$201.88Special order, ships in 7-14 days
4333881Ferrari Clip - 333881$7.86Special order, ships in 7-14 days
5225408Ferrari Cylindrical Bushing - 225408$12.99Special order, ships in 7-14 days
6303321Ferrari Clip - 303321$2.61Special order, ships in 7-14 days
714039614Ferrari NUT - 14039614$0.40Available, ships in 3-6 days
715896214Ferrari Nut M6 x 5 - 15896214SupersededOrder 14039614 instead
8338849Ferrari Header Tank Vent Pipe - 338849$150.17Special order, ships in 7-14 days
913125470Ferrari Collar - 13125470SupersededOrder 13126970 instead
913126970Ferrari Collar - 13126970$3.03Available, ships in 3-6 days
11320347Ferrari Header Tank Rigid Drain Pipe - 320347Price on requestContact us for price and availability
12231617Ferrari Screw M6 x 18 TCEI - 231617SupersededOrder 14433124 instead
13178052Ferrari Clip - 178052$3.26Available, ships in 3-6 days
13296778Ferrari Screw Collar 16- 27mm - 296778SupersededOrder 178052 instead
