Ferrari 488 Pista — [MECHANICAL SYSTEM] - D.29 - COMPLETE WHEELS (diagram 0083)
Exploded view of the [mechanical system] - d.29 - complete wheels on the Ferrari 488 Pista, with 34 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 488 Pista [MECHANICAL SYSTEM] - D.29 - COMPLETE WHEELS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/488-pista/0083.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 108947 | Ferrari Push In Hub Cap - 108947 | Superseded | Order 55059092 instead | |
| 226245 | Ferrari Push In Hub Cap - 226245 | Superseded | Order 55059092 instead | |
| 1 | 342189 | Ferrari Front Rim 9J X 20 Forged Matte Gold - 342189 | $8,352.98 | Special order, ships in 7-14 days |
| 1 | 342906 | Ferrari Front Wheel 9J X 20 - 342906 | Superseded | Order 866267 instead |
| 1 | 70006377 | Ferrari Front Wheel - 70006377 | $12,915.94 | Special order, ships in 7-14 days |
| 1 | 866267 | Ferrari Front Wheel 9J X 20 - 866267 | $16,825.70 | Special order, ships in 7-14 days |
| 1 | 342191 | Ferrari Front Wheel 9J X 20 Forged Matte Black - 342191 | $8,083.59 | Special order, ships in 7-14 days |
| 1 | 819972 | Ferrari Front Wheel 9Jx20 - 819972 | $8,352.98 | Special order, ships in 7-14 days |
| 1 | 342188 | Ferrari Front Wheel 9Jx20 - Matte Grigio Corsa - 342188 | $7,292.00 | Special order, ships in 7-14 days |
| 1 | 342907 | Ferrari Rear Wheel 11J X 20 - 342907 | $21,868.69 | Special order, ships in 7-14 days |
| 1 | 70006378 | Ferrari Rear Wheel 11J x 20 - 70006378 | $13,628.78 | Special order, ships in 7-14 days |
| 1 | 866268 | Ferrari Rear Wheel 11J X 20 - 866268 | $17,242.61 | Special order, ships in 7-14 days |
| 1 | 342195 | Ferrari Rear Wheel 11J X 20 Forged Matte Black - 342195 | $8,643.09 | Special order, ships in 7-14 days |
| 1 | 342193 | Ferrari Rear Wheel 11J X 20 Forged Matte Gold - 342193 | $8,931.12 | Special order, ships in 7-14 days |
| 1 | 819975 | Ferrari Rear Wheel 11Jx20 - 819975 | $8,931.12 | Special order, ships in 7-14 days |
| 1 | 342192 | Ferrari Rear Wheel 11Jx20 Matte Grigio Corsa - 342192 | $7,870.16 | Special order, ships in 7-14 days |
| 2 | 340066 | Ferrari Wheel Center Cap Set - 55059092/4 | Superseded | Order 55059092 instead |
| 2 | 55059092 | Ferrari Wheel Centre Cap - 55059092 | $44.11 | Available, ships in 3-6 days |
| 3 | 11096693 | Ferrari Adhesive Wheel Balancer Weight - 11096693 | $24.32 | Special order, ships in 7-14 days |
| 3 | 308296 | Ferrari Adhesive Wheel Balancer Weight - 308296 | $24.32 | Special order, ships in 7-14 days |
| 4 | 290569 | Ferrari Tyres Pressure Control Sensor - 290569 | $284.11 | Available, ships in 3-6 days |
| 4 | 282189 | Ferrari/Lamborghini/Maserati TPMS Sensor - 282189 | $234.90 | In stock |
| 4 | 282189/4 | Ferrari/Lamborghini/Maserati TPMS Sensor Set of 4 - 282189/4 | $925.00 | In stock |
| 5 | 248171 | Ferrari Tyre Valve - 248171 | $100.51 | Special order, ships in 7-14 days |
| 5 | 185328 | Ferrari/Maserati Tire Valve - 185328 | $26.75 | In stock |
| 6 | 206274 | Ferrari Wheel Bolt -Titanium M14x1.5x16 - 206274 | $348.38 | Available, ships in 3-6 days |
| 7 | 248736 | Ferrari 20" Spare Wheel Rim - 248736 | $3,353.87 | Special order, ships in 7-14 days |
| 8 | 317250104 | Ferrari Tyre Valve - 317250104 | $30.57 | Special order, ships in 7-14 days |
| 9 | 153815 | Ferrari Spare Wheel Label - 153815 | $29.48 | Available, ships in 3-6 days |
| 10 | 70004402 | Ferrari Kit Sostit. Sede Colonn. Cer - 70004402 | $571.13 | Special order, ships in 7-14 days |
| 10 | 70005124 | Ferrari Kit Sostit. Sede Colonn. Cer - 70005124 | $573.70 | Special order, ships in 7-14 days |
| 11 | 70004351 | Ferrari Kit Sostit.Parti In All. Cer - 70004351 | Superseded | Order 70005123 instead |
| 11 | 70005123 | Ferrari Kit Sostit.Parti In All. Cer - 70005123 | $2,393.73 | Special order, ships in 7-14 days |
| 12 | 254075 | Ferrari Ruota Cpl Di Scorta 20 Pneu. - 254075 | $3,761.38 | Special order, ships in 7-14 days |
