Ferrari 488 Pista — [MECHANICAL SYSTEM] - D.32 - STEERING BOX PIPES (diagram 0087)

Exploded view of the [mechanical system] - d.32 - steering box pipes on the Ferrari 488 Pista, with 17 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari 488 Pista [MECHANICAL SYSTEM] - D.32 - STEERING BOX PIPES exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
153419Ferrari Banjo Bolt - 153419SupersededOrder 184727 instead
228142Ferrari Clamp 20.2-22.8x9.2 - 228142SupersededOrder 13126070 instead
222826Ferrari Clip - 222826$5.44Special order, ships in 7-14 days
10261460Ferrari Copper Washer 16x24x1.5 - 10261460$0.63Available, ships in 3-6 days
307858Ferrari Pipe From Pump To Disconnector Union - 307858SupersededOrder 323703 instead
316484Ferrari Power Steering Fluid Reservoir Bracket Complete - 316484SupersededOrder 325786 instead
14432221Ferrari Screw - 14432221SupersededOrder 231619 instead
14433121Ferrari Screw - 14433121SupersededOrder 231617 instead
14432224Ferrari Screw M6 x 22 - 14432224SupersededOrder 231619 instead
2325786Ferrari Power Steering Fluid Reservoir Bracket Complete - 325786$179.73Special order, ships in 7-14 days
3231619Ferrari Screw M6 x 22 - 231619$0.54Available, ships in 3-6 days
12323703Ferrari Pipe From Pump To Disconnector Union - 323703$492.43Special order, ships in 7-14 days
1410257060Ferrari/Maserati Copper Washer - 10257060$1.10In stock
19231617Ferrari Screw M6 x 18 TCEI - 231617SupersededOrder 14433124 instead
21184727Ferrari Banjo bolt For Union M16 x 1.5 - 184727$10.70Available, ships in 3-6 days
2513127070Ferrari Collar - 13127070SupersededOrder 13126070 instead
27263230Ferrari Clip - 263230$2.82Special order, ships in 7-14 days

All 488 Pista diagrams
