Ferrari 488 Pista — [VEHICLE TRIM] - E.14 - FRONT SHIELDS (diagram 0113)
Exploded view of the [vehicle trim] - e.14 - front shields on the Ferrari 488 Pista, with 11 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 488 Pista [VEHICLE TRIM] - E.14 - FRONT SHIELDS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/488-pista/0113.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 89266900 | Ferrari Compl. Front RH Underbody Shield - 89266900 | $465.04 | Special order, ships in 7-14 days |
| 2 | 89266700 | Ferrari Compl. Front LH Underbody Shield - 89266700 | $465.04 | Special order, ships in 7-14 days |
| 3 | 768517 | Ferrari RH Central Front Dam - 768517 | $226.49 | Special order, ships in 7-14 days |
| 4 | 768516 | Ferrari LH Central Front Dam - 768516 | $226.49 | Special order, ships in 7-14 days |
| 5 | 86481400 | Ferrari RH Front Inner Dam - 86481400 | $71.38 | Special order, ships in 7-14 days |
| 6 | 86481300 | Ferrari LH Front Inner Dam - 86481300 | $71.38 | Special order, ships in 7-14 days |
| 7 | 81290900 | Ferrari Screw With Double Washer - 81290900 | $1.42 | In stock |
| 8 | 86607000 | Ferrari Screw - 86607000 | Superseded | Order 256490 instead |
| 8 | 256490 | Ferrari Screw TBEI M5 x 16 - 256490 | $3.91 | Available, ships in 3-6 days |
| 9 | 12643701 | Ferrari Flat Washer - 12643701 | $0.12 | Available, ships in 3-6 days |
| 10 | 85833900 | Ferrari Screw M5 x 16 TBFTX - 85833900 | $0.65 | Available, ships in 3-6 days |
