Ferrari 488 Pista — [VEHICLE TRIM] - E.18 - REAR WHEELHOUSE (diagram 0117)
Exploded view of the [vehicle trim] - e.18 - rear wheelhouse on the Ferrari 488 Pista, with 7 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 488 Pista [VEHICLE TRIM] - E.18 - REAR WHEELHOUSE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/488-pista/0117.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 89270100 | Ferrari Compl. RH Rear WheeLHouse - 89270100 | $1,050.54 | Special order, ships in 7-14 days |
| 2 | 89268800 | Ferrari Compl. LH Rear Wheel House - 89268800 | $1,050.54 | Special order, ships in 7-14 days |
| 3 | 89268700 | Ferrari Compl. RH Rear Wheel Gravel - 89268700 | $154.46 | Special order, ships in 7-14 days |
| 3 | 795710 | Ferrari Compl. RH Rear Wheel Gravel Guard - 795710 | $522.16 | Special order, ships in 7-14 days |
| 4 | 89268500 | Ferrari Compl. LH Rear Wheel Gravel - 89268500 | $154.46 | Special order, ships in 7-14 days |
| 4 | 795711 | Ferrari Compl. LH Rear Wheel Gravel Guard - 795711 | $522.16 | Special order, ships in 7-14 days |
| 5 | 88164800 | Ferrari Undertray Screw TBEI M6 x 15 - 88164800 | $1.53 | Special order, ships in 7-14 days |
