Ferrari 488 Pista — [VEHICLE TRIM] - E.33 - FRONT LID TRIM (diagram 0134)
Exploded view of the [vehicle trim] - e.33 - front lid trim on the Ferrari 488 Pista, with 20 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 488 Pista [VEHICLE TRIM] - E.33 - FRONT LID TRIM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/488-pista/0134.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 264882 | Ferrari Dynamic Intake Filler Foam - 264882 | Superseded | Order 83081700 instead | |
| 80131500 | Ferrari Spray Nozzle - 80131500 | Superseded | Order 65191000 instead | |
| 1 | 785272 | Ferrari Compl. Screen Washer Pipe As - 785272 | $140.32 | Special order, ships in 7-14 days |
| 2 | 83807100 | Ferrari Front Lid Air Duct Seal LHD - 83807100 | $211.73 | Special order, ships in 7-14 days |
| 2 | 83341000 | Ferrari Front Lid Air Duct Seal RHD - 83341000 | $270.83 | Available, ships in 3-6 days |
| 3 | 65191000 | Ferrari Spray Nozzle - 65191000 | $5.44 | Available, ships in 3-6 days |
| 4 | 83081700 | Ferrari Dynamic Intake Filler Foam - 83081700 | $27.47 | Available, ships in 3-6 days |
| 5 | 87420200 | Ferrari Anti-Vibration Rubber Pipe - 87420200 | $14.01 | Special order, ships in 7-14 days |
| 6 | 103549 | Ferrari Grommet - 103549 | $2.80 | In stock |
| 7 | 785249 | Ferrari Rubber Pipe - 785249 | $6.38 | Special order, ships in 7-14 days |
| 8 | 785251 | Ferrari Rubber Pipe - 785251 | $3.41 | Special order, ships in 7-14 days |
| 9 | 15783177 | Ferrari Screw - 15783177 | $5.04 | Available, ships in 3-6 days |
| 10 | 14115580 | Ferrari Fixing Block - 14115580 | $0.34 | Available, ships in 3-6 days |
| 11 | 13550278 | Ferrari Washer D.6x13x1 - 13550278 | $1.80 | Available, ships in 3-6 days |
| 12 | 82139200 | Ferrari Striker Plate - 82139200 | $66.35 | Special order, ships in 7-14 days |
| 13 | 14054577 | Ferrari Domed Nut - 14054577 | $0.59 | Available, ships in 3-6 days |
| 14 | 87294800 | Ferrari Spacer - 87294800 | $1.36 | Special order, ships in 7-14 days |
| 15 | 84827800 | Ferrari Lid Striker Plate Film - 84827800 | $16.81 | Special order, ships in 7-14 days |
| 16 | 844317 | Ferrari Film For Lid Hinge - 844317 | Price on request | Contact us for price and availability |
| 17 | 14621887 | Ferrari Cover - 14621887 | $3.26 | Special order, ships in 7-14 days |
