Ferrari 488 Pista — [ELECTRICAL SYSTEM] - F.13 - DATA LOGGER SYSTEM (diagram 0188)
Exploded view of the [electrical system] - f.13 - data logger system on the Ferrari 488 Pista, with 46 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 488 Pista [ELECTRICAL SYSTEM] - F.13 - DATA LOGGER SYSTEM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/488-pista/0188.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 242694 | Ferrari GPS Antenna - 242694 | Price on request | Contact us for price and availability | |
| 331961 | Ferrari GPS Antenna - 331961 | $154.46 | Special order, ships in 7-14 days | |
| 320530 | Ferrari Lvds Cable - 320530 | Superseded | Order 820273 instead | |
| 931307432 | Ferrari Navigation System Gps Antenna - 931307432 | Superseded | Order 789209 instead | |
| 309771 | Ferrari Ndm Usb Cable - 309771 | $489.54 | Special order, ships in 7-14 days | |
| 307986 | Ferrari Telemetry USB Key Kit - 307986 | Superseded | Order 323616 instead | |
| 1 | 314677 | Ferrari Ntm Telemetry Node - 314677 | $19,127.17 | Contact us to order |
| 2 | 302297 | Ferrari WiFi Antenna NTM Connector - 302297 | $137.04 | Special order, ships in 7-14 days |
| 3 | 316336 | Ferrari Complete Telemetry ECU Mounting Bracket - 316336 | $163.97 | Special order, ships in 7-14 days |
| 3 | 310734 | Ferrari Telemetry Ecu Mounting Bracket Complete - 310734 | $97.88 | Special order, ships in 7-14 days |
| 4 | 16281827 | Ferrari Screw 5x14 - 16281827 | $0.46 | Special order, ships in 7-14 days |
| 5 | 86876400 | Ferrari Screw M4 x 14 TBEI - 86876400 | $15.49 | Special order, ships in 7-14 days |
| 6 | 292422 | Ferrari Passenger Compartment Telemetry Camera - 292422 | $7,958.75 | Special order, ships in 7-14 days |
| 7 | 292423 | Ferrari External Telemetry Camera - 292423 | $7,958.75 | Special order, ships in 7-14 days |
| 8 | 292912 | Ferrari Passenger Compartment Telemetry Camera Cable - 292912 | $215.38 | Special order, ships in 7-14 days |
| 9 | 292913 | Ferrari External Telemetry Camera Cable - 292913 | $215.38 | Special order, ships in 7-14 days |
| 10 | 813311 | Ferrari Lvds Nit Vp4 Cable - 813311 | $1,223.87 | Special order, ships in 7-14 days |
| 11 | 284501 | Ferrari LVDS Cable - 284501 | $1,346.25 | Special order, ships in 7-14 days |
| 12 | 304258 | Ferrari USB-Telemetry Node Cable - 304258 | $215.38 | Special order, ships in 7-14 days |
| 13 | 286161 | Ferrari WiFi Antenna - 286161 | $415.25 | Special order, ships in 7-14 days |
| 14 | 312871 | Ferrari Compl. Ndc/Ndm Control Unit Mounting Bracket. - 312871 | $141.95 | Special order, ships in 7-14 days |
| 14 | 316341 | Ferrari Ndc/Ndm Control Unit Complete - 316341 | $44.03 | Special order, ships in 7-14 days |
| 15 | 14302921 | Ferrari Screw M4 x 10 - 14302921 | $0.17 | Available, ships in 3-6 days |
| 16 | 770070 | Ferrari Carplay Ecu - 770070 | $14,343.93 | Contact us to order |
| 17 | 311948 | Ferrari Ndm Usb Cable - 311948 | $491.74 | Special order, ships in 7-14 days |
| 18 | 311025 | Ferrari VP4/NDM LVDS Cable - 311025 | $1,346.25 | Available, ships in 3-6 days |
| 19 | 813310 | Ferrari LVDS Nit-Ntm Cable - 813310 | $1,346.25 | Special order, ships in 7-14 days |
| 20 | 305233 | Ferrari NQS-NTM LVDS Cable - 305233 | $1,444.15 | Special order, ships in 7-14 days |
| 21 | 293328 | Ferrari GPS Antenna Splitter - 293328 | $489.54 | Special order, ships in 7-14 days |
| 21 | 342543 | Ferrari Splitter Antenna Gpsntm Lead - 342543 | $305.96 | Special order, ships in 7-14 days |
| 22 | 310707 | Ferrari Parking Camera Dashboard Wiring Harness LHD - 310707 | $443.17 | Special order, ships in 7-14 days |
| 22 | 303627 | Ferrari Parking Camera Dashboard Wiring Harness RHD - 303627 | $664.78 | Special order, ships in 7-14 days |
| 23 | 317027 | Ferrari Clip - 317027 | $1.02 | Special order, ships in 7-14 days |
| 24 | 770069 | Ferrari Parking System Ecu - 770069 | $3,030.56 | Special order, ships in 7-14 days |
| 25 | 313124 | Ferrari Parking Camera Wiring Harness - 313124 | $440.56 | Special order, ships in 7-14 days |
| 26 | 789209 | Ferrari GPS Antenna - 789209 | $155.15 | Special order, ships in 7-14 days |
| 27 | 283375 | Ferrari GPS Antenna Extension Cable - 283375 | $130.29 | Special order, ships in 7-14 days |
| 28 | 301322 | Ferrari GPS Antenna-NIT Splitter Extension Cable - 301322 | $115.54 | Special order, ships in 7-14 days |
| 29 | 304817 | Ferrari GPS Antenna-NTM Cable - 304817 | $177.00 | Special order, ships in 7-14 days |
| 29 | 302295 | Ferrari GPS Antenna-NTM Splitter Extension Cable - 302295 | $179.46 | Special order, ships in 7-14 days |
| 30 | 297469 | Ferrari USB Nit Cable - 297469 | $230.06 | Special order, ships in 7-14 days |
| 31 | 813309 | Ferrari Lvds Cable - 813309 | $1,003.57 | Special order, ships in 7-14 days |
| 31 | 820273 | Ferrari Lvds Cable - 820273 | $2,074.75 | Special order, ships in 7-14 days |
| 32 | 310118 | Ferrari GPS Antenna Dashboard Antenna Extension Cable - 310118 | $68.50 | Special order, ships in 7-14 days |
| 33 | 323616 | Ferrari Telemetry Usb Key Kit - 323616 | $663.86 | Special order, ships in 7-14 days |
| 34 | 323618 | Ferrari 4 - language Manual for Telemetry - 323618 | $88.09 | Special order, ships in 7-14 days |
