Ferrari 512 BB (Carburetor) — Insulating Material And Bulkheads (diagram 105)
Exploded view of the insulating material and bulkheads on the Ferrari 512 BB (Carburetor), with 39 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/105.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 50046200 | Ferrari Gasket - 50046200 | Price on request | Contact us for price and availability |
| 2 | 50046309 | Ferrari Gasket - 50046309 | Price on request | Contact us for price and availability |
| 3 | 50042308 | Ferrari Central Cloth Piece - 50042308 | Price on request | Contact us for price and availability |
| 4 | 50042407 | Ferrari Cloth Piece Black - 50042407 | Price on request | Contact us for price and availability |
| 5 | 50100700 | Ferrari Foam Piece - 50100700 | $138.02 | Available, ships in 3-6 days |
| 6 | 50100403 | Ferrari Foam Piece - 50100403 | Price on request | Contact us for price and availability |
| 7 | 50100809 | Ferrari Trim - 50100809 | $219.19 | Special order, ships in 7-14 days |
| 8 | 50042100 | Ferrari Panel - 50042100 | $191.57 | Available, ships in 3-6 days |
| 9 | 50099307 | Ferrari Trim Panel - 50099307 | Price on request | Contact us for price and availability |
| 10 | 50099406 | Ferrari Trim Panel - 50099406 | Price on request | Contact us for price and availability |
| 11 | 50101302 | Ferrari Spare Wheel Cover - 50101302 | Price on request | Contact us for price and availability |
| 11 | 50319904 | Ferrari Spare Wheel Cover LHD - 50319904 | Price on request | Contact us for price and availability |
| 12 | 50101500 | Ferrari Strap - 50101500 | Price on request | Contact us for price and availability |
| 13 | 104550 | Ferrari Air Box/Battery Cover Knurled Nut - 104550 | $13.20 | In stock |
| 13 | 30062608 | Ferrari Knurled Nut - 30062608 | $13.57 | Available, ships in 3-6 days |
| 14 | 50072008 | Ferrari RH Insulation - 50072008 | Price on request | Contact us for price and availability |
| 14 | 50072107 | Ferrari LH Insulation - 50072107 | Price on request | Contact us for price and availability |
| 15 | 50072206 | Ferrari RH Insulation - 50072206 | Price on request | Contact us for price and availability |
| 15 | 50072305 | Ferrari LH Insulation - 50072305 | Price on request | Contact us for price and availability |
| 16 | 50332600 | Ferrari Battery Cover - 50332600 | Price on request | Contact us for price and availability |
| 17 | 50155100 | Ferrari Terminal - 50155100 | Price on request | Contact us for price and availability |
| 18 | 50137306 | Ferrari Strap - 50137306 | Price on request | Contact us for price and availability |
| 19 | 50309509 | Ferrari Bulkhead Cover LHD - 50309509 | $927.76 | Available, ships in 3-6 days |
| 19 | 50348002 | Ferrari Bulkhead Cover RHD - 50348002 | Price on request | Contact us for price and availability |
| 20 | 20033007 | Ferrari Bolt - 20033007 | Price on request | Contact us for price and availability |
| 21 | 50157106 | Ferrari Angle Bar - 50157106 | Price on request | Contact us for price and availability |
| 22 | 50093608 | Ferrari Panel - 50093608 | Price on request | Contact us for price and availability |
| 23 | 50341809 | Ferrari Heat Shield /Bulkhead - 50341809 | Price on request | Contact us for price and availability |
| 24 | 10902024 | Ferrari Screw M6 x 12 - 10902024 | $0.12 | Available, ships in 3-6 days |
| 24 | 10902411 | Ferrari Bolt - 10902411 | Superseded | Order 10902024 instead |
| 25 | 12643701 | Ferrari Flat Washer - 12643701 | $0.12 | Available, ships in 3-6 days |
| 26 | 50161603 | Ferrari Earth Strap - 50161603 | Price on request | Contact us for price and availability |
| 27 | 50043009 | Ferrari Fuel Filler Surround - 50043009 | Price on request | Contact us for price and availability |
| 28 | 50117605 | Ferrari Insulation LHD - 50117605 | Price on request | Contact us for price and availability |
| 29 | 50117704 | Ferrari Insulation - 50117704 | Price on request | Contact us for price and availability |
| 30 | 50205509 | Ferrari Insulation - 50205509 | Price on request | Contact us for price and availability |
| 20030003 | Ferrari Bolt M6x1 L30 - 20030003 | Price on request | Contact us for price and availability | |
| 10902011 | Ferrari Screw 6x12 - 10902011 | $13.69 | Available, ships in 3-6 days | |
| - | 50214600 | Ferrari Housing Cover Set - 50214600 | Price on request | Contact us for price and availability |
