Ferrari 550 Maranello — Boot Upholstery (diagram 115)
Exploded view of the boot upholstery on the Ferrari 550 Maranello, with 13 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 8 | 65045800 | Ferrari Black Sill Trim Cover - 65045800 | Price on request | Contact us for price and availability |
| 9 | 12678707 | Ferrari Screw - 12678707 | Price on request | Contact us for price and availability |
| 10 | 12611307 | Ferrari Cup Washer - 12611307 | Price on request | Contact us for price and availability |
| 11 | 62931000 | Ferrari Knob - 62931000 | $7.55 | Available, ships in 3-6 days |
| 12 | 65044200 | Ferrari Bracket - 65044200 | $26.89 | Special order, ships in 7-14 days |
| 12 | 65044400 | Ferrari LH Bracket - 65044400 | $26.89 | Special order, ships in 7-14 days |
| 13 | 65032900 | Ferrari Pad - 65032900 | $0.52 | Special order, ships in 7-14 days |
| 14 | 64569100 | Ferrari Cover - 64569100 | Price on request | Contact us for price and availability |
| 15 | 65116200 | Ferrari Threaded Pin - 65116200 | Superseded | Order 64576600 instead |
| 16 | 12674002 | Ferrari Screw - 12674002 | Superseded | Order 12674102 instead |
| 16 | 12674102 | Ferrari Screw - 12674102 | $1.17 | Available, ships in 3-6 days |
| 18 | 14215480 | Ferrari Plastic Screw Block D4 - 14215480 | $0.46 | Available, ships in 3-6 days |
| 64576600 | Ferrari Threaded Pin - 64576600 | $4.62 | Special order, ships in 7-14 days |
