Ferrari 575M Maranello — Inner Trims (diagram 126)
Exploded view of the inner trims on the Ferrari 575M Maranello, with 36 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 3 | 15782601 | Ferrari Screw - 15782601 | Price on request | Contact us for price and availability |
| 4 | 64946300 | Ferrari Lamp Bracket - 64946300 | $31.80 | Special order, ships in 7-14 days |
| 5 | 14641491 | Ferrari Rivet 3.2x10 - 14641491 | $0.19 | Available, ships in 3-6 days |
| 6 | 15803007 | Ferrari Screw - 15803007 | $1.04 | Special order, ships in 7-14 days |
| 7 | 14371974 | Ferrari Small Bracket - 14371974 | $3.89 | Special order, ships in 7-14 days |
| 8 | 12638124 | Ferrari Washer - 12638124 | $0.08 | Available, ships in 3-6 days |
| 11 | 64590900 | Ferrari Plate - 64590900 | $5.37 | Special order, ships in 7-14 days |
| 12 | 15901375 | Ferrari Screw - 15901375 | $0.50 | Special order, ships in 7-14 days |
| 13 | 66092400 | Ferrari Trim Clip - 66092400 | $0.25 | In stock |
| 13 | 14188181 | Ferrari Plastic Trim Clip - 14188181 | $0.50 | Available, ships in 3-6 days |
| 17 | 13046011 | Ferrari Flanged Nut - 13046011 | $0.73 | Available, ships in 3-6 days |
| 19 | 183365 | Ferrari Loud Speaker - 183365 | $189.27 | Special order, ships in 7-14 days |
| 19 | 184677 | Ferrari Loud Speaker - 184677 | Price on request | Contact us for price and availability |
| 20 | 10794014 | Ferrari Nut M4 x 3.2 - 10794014 | $0.59 | Available, ships in 3-6 days |
| 21 | 12642801 | Ferrari Washer - 12642801 | $0.19 | Available, ships in 3-6 days |
| 22 | 175856 | Ferrari Bracket - 175856 | $4.54 | Special order, ships in 7-14 days |
| 23 | 13577701 | Ferrari Washer 5.15 - 15 x 1.2 - 13577701 | $0.19 | Available, ships in 3-6 days |
| 24 | 66284800 | Ferrari Bracket - 66284800 | $220.26 | Special order, ships in 7-14 days |
| 24 | 66284900 | Ferrari Bracket - 66284900 | $220.26 | Special order, ships in 7-14 days |
| 25 | 16084201 | Ferrari Screw - 16084201 | $3.24 | Available, ships in 3-6 days |
| 27 | 66285000 | Ferrari Speaker Moulding - 66285000 | Price on request | Contact us for price and availability |
| 32 | 13309477 | Ferrari Screw 5x20 - 13309477 | $0.79 | Special order, ships in 7-14 days |
| 33 | 12611307 | Ferrari Cup Washer - 12611307 | Price on request | Contact us for price and availability |
| 35 | 14059111 | Ferrari Flanged Nut M5 - 14059111 | $0.08 | Available, ships in 3-6 days |
| 35 | 14039511 | Ferrari Nut - 14039511 | $0.54 | Available, ships in 3-6 days |
| 37 | 66612100 | Ferrari Bracket - 66612100 | $188.45 | Special order, ships in 7-14 days |
| 38 | 66624800 | Ferrari Screw - 66624800 | $2.80 | Special order, ships in 7-14 days |
| 39 | 14496578 | Ferrari Washer - 14496578 | $0.38 | Available, ships in 3-6 days |
| 40 | 12601377 | Ferrari Washer - 12601377 | $0.06 | Available, ships in 3-6 days |
| 40 | 12601374 | Ferrari Wavy Washer 8mm - 12601374 | $3.12 | Available, ships in 3-6 days |
| 14040514 | Ferrari Flanged Nut - 14040514 | Superseded | Order 13046011 instead | |
| 13046012 | Ferrari Nut - 13046012 | Superseded | Order 13046011 instead | |
| 14039614 | Ferrari NUT - 14039614 | $0.40 | Available, ships in 3-6 days | |
| 13550405 | Ferrari Washer - 13550405 | Superseded | Order 14496578 instead | |
| 14496506 | Ferrari Washer - 14496506 | Superseded | Order 14496578 instead | |
| 14496507 | Ferrari Washer - 14496507 | Superseded | Order 14496578 instead |
