Ferrari 599 SA Aperta — Rollbar (diagram 102)
Exploded view of the rollbar on the Ferrari 599 SA Aperta, with 22 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 83062200 | Ferrari Compl. Rollbar - 83062200 | $5,368.77 | Special order, ships in 7-14 days |
| 3 | 83023800 | Ferrari Upper Seal - 83023800 | $954.60 | Special order, ships in 7-14 days |
| 4 | 83023700 | Ferrari Lunotto Dx Rollbar - 83023700 | $2,010.00 | Contact us to order |
| 5 | 83023500 | Ferrari Lunotto Sx Rollbar - 83023500 | $2,010.00 | Contact us to order |
| 6 | 83572610 | Ferrari Rivestim. Pinna Rollbar Dx.C - 83572610 | $10,390.20 | Contact us to order |
| 7 | 83572510 | Ferrari Rivestim. Pinna Rollbar Sx.C - 83572510 | $10,390.20 | Contact us to order |
| 8 | 83496510 | Ferrari Riporto Aerodinamico Dx. Sem - 83496510 | $17,083.10 | Contact us to order |
| 9 | 83496810 | Ferrari Riporto Aerodinamico Sx.Semi - 83496810 | $16,393.07 | Contact us to order |
| 10 | 16286024 | Ferrari SCREW - 16286024 | $0.38 | Available, ships in 3-6 days |
| 11 | 12620474 | Ferrari Wavy Washer - 12620474 | $0.12 | Available, ships in 3-6 days |
| 12 | 10523424 | Ferrari Washer D 6.15-18x2 - 10523424 | $0.92 | Available, ships in 3-6 days |
| 13 | 65841100 | Ferrari Black Foam Washer - Self Adhesive - 65841100 | $2.13 | Available, ships in 3-6 days |
| 14 | 83721600 | Ferrari Centring Bracket On Seal - 83721600 | $36.95 | Special order, ships in 7-14 days |
| 15 | 15915077 | Ferrari Screw - 15915077 | $2.07 | Available, ships in 3-6 days |
| 16 | 84179400 | Ferrari 0.5 Mm Adjuster Plate - 84179400 | $90.54 | Special order, ships in 7-14 days |
| 16 | 84179600 | Ferrari 1 Mm Adjuster Plate - 84179600 | $95.43 | Special order, ships in 7-14 days |
| 16 | 84179500 | Ferrari 2 Mm Adjuster Plate - 84179500 | $102.77 | Special order, ships in 7-14 days |
| 17 | 84223300 | Ferrari Seal Drain Fastener Tube - 84223300 | Price on request | Contact us for price and availability |
| 18 | 83334900 | Ferrari Gasket - 83334900 | $239.31 | Special order, ships in 7-14 days |
| 19 | 83358600 | Ferrari 0.5 Mm Adjuster Plate - 83358600 | $90.54 | Special order, ships in 7-14 days |
| 19 | 83358700 | Ferrari 1 Mm Adjuster Plate - 83358700 | $95.43 | Special order, ships in 7-14 days |
| 19 | 83358800 | Ferrari 2 Mm Adjuster Plate - 83358800 | $102.77 | Special order, ships in 7-14 days |
