Ferrari 812 Competizione — [ENGINE] - B.4 - CRANKSHAFT (diagram 0007)

Exploded view of the [engine] - b.4 - crankshaft on the Ferrari 812 Competizione, with 16 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari 812 Competizione [ENGINE] - B.4 - CRANKSHAFT exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
1985696Ferrari Crankshaft - 985696$7,096.58Special order, ships in 7-14 days
214328801Ferrari Plug - 14328801$0.65Special order, ships in 7-14 days
3176396Ferrari Threaded Plug D. 28 x 1.5 - 176396$10.42Available, ships in 3-6 days
4103877Ferrari/Maserati Clutch Pilot Bearing - 103877$32.95In stock
5190981Ferrari Woodruff Key - 190981$2.01Special order, ships in 7-14 days
6313688Ferrari Lower Half-Bearing - 313688$44.24Special order, ships in 7-14 days
6313687Ferrari Lower Main Half Bearing Brown - 313687$44.24Special order, ships in 7-14 days
6271025Ferrari Lower Main Half Bearing Green - 271025$58.98Available, ships in 3-6 days
6800695Ferrari Lower Main Half Bearing Orange - 800695$44.24Special order, ships in 7-14 days
6271024Ferrari Lower Main Half Bearing Yellow - 271024$61.45Special order, ships in 7-14 days
7313685Ferrari Upper Half-Bearing - 313685$44.24Special order, ships in 7-14 days
7313686Ferrari Upper Half-Bearing - 313686$44.24Special order, ships in 7-14 days
7800694Ferrari Upper Half-Bearing - 800694$46.69Special order, ships in 7-14 days
7271030Ferrari Upper Main Half Bearing Green - 271030$58.98Available, ships in 3-6 days
7271029Ferrari Upper Main Half Bearing Yellow - 271029$61.45Available, ships in 3-6 days
8261727Ferrari Crankshaft Bearing Shim - 261727$16.69Available, ships in 3-6 days
