Ferrari 812 Competizione — [MECHANICAL SYSTEM] - D.7 - EXHAUST MANIFOLD (diagram 0055)
Exploded view of the [mechanical system] - d.7 - exhaust manifold on the Ferrari 812 Competizione, with 15 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 812 Competizione [MECHANICAL SYSTEM] - D.7 - EXHAUST MANIFOLD exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/812-competizione/0055.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 880349 | Ferrari Collett. Di Scaric0 Sx Con S - 880349 | $6,819.08 | Special order, ships in 7-14 days | |
| 880348 | Ferrari Collett. Di Scarico Dx Con S - 880348 | $6,819.08 | Special order, ships in 7-14 days | |
| 14039614 | Ferrari NUT - 14039614 | $0.40 | Available, ships in 3-6 days | |
| 1 | 774713 | Ferrari LH Exhaust Manifold - 774713 | $7,324.90 | Special order, ships in 7-14 days |
| 1 | 774712 | Ferrari RH Exhaust Manifold - 774712 | $7,327.23 | Special order, ships in 7-14 days |
| 2 | 212702 | Ferrari Exhaust Manifold Gasket - 212702 | $13.60 | In stock |
| 3 | 210971 | Ferrari Copper Exhaust Nut - 210971 | $3.25 | In stock |
| 4 | 821253 | Ferrari Paratia Anticalore Testa Dx - 821253 | $368.79 | Special order, ships in 7-14 days |
| 4 | 821250 | Ferrari Paratia Anticalore Testa Sx - 821250 | $417.97 | Special order, ships in 7-14 days |
| 5 | 233600 | Ferrari/Maserati Screw - 233600 | $1.98 | In stock |
| 6 | 11628424 | Ferrari Screw 6X14 - 11628424 | $1.28 | Special order, ships in 7-14 days |
| 7 | 821255 | Ferrari Paratia Anticalore Testa Dx - 821255 | $467.15 | Special order, ships in 7-14 days |
| 7 | 821252 | Ferrari Paratia Anticalore Testa Sx - 821252 | $467.15 | Special order, ships in 7-14 days |
| 8 | 15896214 | Ferrari Nut M6 x 5 - 15896214 | Superseded | Order 14039614 instead |
| 9 | 11625524 | Ferrari Screw - 11625524 | $1.53 | Special order, ships in 7-14 days |
