Ferrari 812 Competizione — [MECHANICAL SYSTEM] - D.23.02 - HYDRAULIC BRAKE CONTROL PIPES -Applicable for RHD- (diagram 0073)
Exploded view of the [mechanical system] - d.23.02 - hydraulic brake control pipes -applicable for rhd- on the Ferrari 812 Competizione, with 20 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 812 Competizione [MECHANICAL SYSTEM] - D.23.02 - HYDRAULIC BRAKE CONTROL PIPES -Applicable for RHD- exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/812-competizione/0073.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 284627 | Ferrari Pipe From Disconnector To RH Rear Wheel - 284627 | $113.08 | Special order, ships in 7-14 days |
| 2 | 284624 | Ferrari Pipe From Disconnector To LH Rear Wheel - 284624 | $115.54 | Special order, ships in 7-14 days |
| 3 | 116374 | Ferrari/Maserati Clip - 116374 | $3.20 | In stock |
| 4 | 284622 | Ferrari Clip - 284622 | $3.47 | Special order, ships in 7-14 days |
| 5 | 234285 | Ferrari Clip - 234285 | $1.40 | Available, ships in 3-6 days |
| 6 | 241118 | Ferrari Clip - 241118 | $4.98 | Special order, ships in 7-14 days |
| 7 | 324554 | Ferrari Pipe From Unit To LH Rear Wheel Disconnecter - 324554 | $90.95 | Special order, ships in 7-14 days |
| 8 | 324555 | Ferrari Pipe From Unit To LH Rear Wheel Disconnecter - 324555 | $189.31 | Special order, ships in 7-14 days |
| 9 | 291250 | Ferrari Clip - 291250 | $1.49 | Special order, ships in 7-14 days |
| 10 | 324556 | Ferrari Pipe From Unit To RH Front Wheel Disconnecter - 324556 | $88.49 | Special order, ships in 7-14 days |
| 11 | 324553 | Ferrari Pipe From Unit To LH Front Wheel - 324553 | $152.41 | Special order, ships in 7-14 days |
| 12 | 287846 | Ferrari Pipe From Disconnector To RH Front Wheel RHD - 287846 | $88.49 | Special order, ships in 7-14 days |
| 13 | 234286 | Ferrari Clip - 234286 | $3.03 | Available, ships in 3-6 days |
| 14 | 217156 | Ferrari Rubber Shim - 217156 | $1.21 | Available, ships in 3-6 days |
| 15 | 234284 | Ferrari Clip - 234284 | $1.23 | Available, ships in 3-6 days |
| 16 | 291251 | Ferrari Clip - 291251 | $1.49 | Special order, ships in 7-14 days |
| 17 | 262737 | Ferrari Rubber Retainer - 262737 | $10.06 | Special order, ships in 7-14 days |
| 18 | 296332 | Ferrari Brake Pipe Mounting Bracket - 296332 | $83.57 | Special order, ships in 7-14 days |
| 19 | 324551 | Ferrari Pipe From Master Cylinder To Unit Primary Inlet - 324551 | $90.95 | Special order, ships in 7-14 days |
| 20 | 324552 | Ferrari Pipe From Master Cylinder To Unit Secondary Inlet - 324552 | $86.04 | Special order, ships in 7-14 days |
