Ferrari 812 Competizione — [VEHICLE TRIM] - E.24 - REAR AIR INTAKES (diagram 0123)
Exploded view of the [vehicle trim] - e.24 - rear air intakes on the Ferrari 812 Competizione, with 7 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 812 Competizione [VEHICLE TRIM] - E.24 - REAR AIR INTAKES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/812-competizione/0123.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 799140 | Ferrari Compl. Canister Protection C - 799140 | $270.44 | Special order, ships in 7-14 days |
| 2 | 859226 | Ferrari Compl. RH WheeLHouse Fastene - 859226 | $56.52 | Special order, ships in 7-14 days |
| 3 | 81591700 | Ferrari Screw TE M6 x 18 with washer - 81591700 | $4.12 | Available, ships in 3-6 days |
| 4 | 819511 | Ferrari Compl. RH WheeLHouse Fastene - 819511 | $31.93 | Special order, ships in 7-14 days |
| 5 | 847018 | Ferrari Compl. LH WheeLHouse Fastene - 847018 | $31.93 | Special order, ships in 7-14 days |
| 6 | 13833224 | Ferrari Screw - 13833224 | $0.33 | Available, ships in 3-6 days |
| 7 | 13577701 | Ferrari Washer 5.15 - 15 x 1.2 - 13577701 | $0.19 | Available, ships in 3-6 days |
