Ferrari 812 Competizione — [ELECTRICAL SYSTEM] - F.5 - OTHER ELECTRICAL DEVICES (diagram 0180)
Exploded view of the [electrical system] - f.5 - other electrical devices on the Ferrari 812 Competizione, with 8 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 812 Competizione [ELECTRICAL SYSTEM] - F.5 - OTHER ELECTRICAL DEVICES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/812-competizione/0180.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 340072 | Ferrari Horn - 340072 | Superseded | Order 785918 instead | |
| 1 | 785918 | Ferrari Horn - 785918 | $262.24 | Special order, ships in 7-14 days |
| 2 | 16287024 | Ferrari Screw - 16287024 | $1.00 | In stock |
| 3 | 984938 | Ferrari Horn Fastener Bracket - 984938 | $34.40 | Special order, ships in 7-14 days |
| 4 | 16296934 | Ferrari Screw 6x14 - 16296934 | $0.90 | Special order, ships in 7-14 days |
| 5 | 215406 | Ferrari 12V Socket - 215406 | $71.28 | Available, ships in 3-6 days |
| 6 | 847648 | Ferrari Two-Tone Infoled - 847648 | $194.22 | Special order, ships in 7-14 days |
| 7 | 16082801 | Ferrari Screw - 16082801 | $0.06 | Special order, ships in 7-14 days |
