Ferrari 812 CompetizioneA — [VEHICLE TRIM] - E.15 - CENTRE SHIELDS (diagram 0114)
Exploded view of the [vehicle trim] - e.15 - centre shields on the Ferrari 812 CompetizioneA, with 12 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 812 CompetizioneA [VEHICLE TRIM] - E.15 - CENTRE SHIELDS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/812-competizionea/0114.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 11197779 | Ferrari Washer - 11197779 | Superseded | Order 11197774 instead | |
| 14498804 | Ferrari Washer - 14498804 | Superseded | Order 14498824 instead | |
| 1 | 88084100 | Ferrari Compl. RH Centre Flat Undert - 88084100 | $491.74 | Special order, ships in 7-14 days |
| 2 | 88084000 | Ferrari Compl. LH Centre Flat Undertray - 88084000 | $491.74 | Special order, ships in 7-14 days |
| 3 | 82115900 | Ferrari Screw M6 x 14 With Washer - 82115900 | $1.23 | Available, ships in 3-6 days |
| 4 | 12578111 | Ferrari Flanged Nyloc Nut - 12578111 | $0.50 | Available, ships in 3-6 days |
| 5 | 12640624 | Ferrari Plain Washer 6mm - 12640624 | $0.31 | Available, ships in 3-6 days |
| 6 | 81290900 | Ferrari Screw With Double Washer - 81290900 | $1.42 | In stock |
| 7 | 13837017 | Ferrari Screw 6X30 - 13837017 | $7.19 | Special order, ships in 7-14 days |
| 8 | 12647778 | Ferrari Cup Washer - 12647778 | $0.82 | Available, ships in 3-6 days |
| 9 | 10902824 | Ferrari Screw M6 x 30 - 10902824 | $0.17 | Available, ships in 3-6 days |
| 10 | 11197774 | Ferrari Conic Washer 6.4x12x1.2 - 11197774 | $0.12 | Available, ships in 3-6 days |
