Ferrari 812 CompetizioneA — [VEHICLE TRIM] - E.16 - REAR SHIELDS (diagram 0115)
Exploded view of the [vehicle trim] - e.16 - rear shields on the Ferrari 812 CompetizioneA, with 10 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 812 CompetizioneA [VEHICLE TRIM] - E.16 - REAR SHIELDS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/812-competizionea/0115.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 798773 | Ferrari Compl. Rear Flat Undertray - 798773 | $934.32 | Contact us to order |
| 2 | 798772 | Ferrari RH Rear Dam Rear Part - 798772 | $152.41 | Special order, ships in 7-14 days |
| 3 | 798771 | Ferrari LH Rear Dam Rear Part - 798771 | $159.79 | Special order, ships in 7-14 days |
| 4 | 12643701 | Ferrari Flat Washer - 12643701 | $0.12 | Available, ships in 3-6 days |
| 5 | 85833900 | Ferrari Screw M5 x 16 TBFTX - 85833900 | $0.65 | Available, ships in 3-6 days |
| 6 | 906179 | Ferrari Pelosato Clip - 906179 | $3.91 | Special order, ships in 7-14 days |
| 7 | 81591700 | Ferrari Screw TE M6 x 18 with washer - 81591700 | $4.12 | Available, ships in 3-6 days |
| 7 | 81290900 | Ferrari Screw With Double Washer - 81290900 | $1.42 | In stock |
| 8 | 10523424 | Ferrari Washer D 6.15-18x2 - 10523424 | $0.92 | Available, ships in 3-6 days |
| 9 | 10902824 | Ferrari Screw M6 x 30 - 10902824 | $0.17 | Available, ships in 3-6 days |
